Product
Weidmueller
1180290000
TOS 120VAC/48VDC 0.5A RC
Request a Quote
Image copyright: Weidmueller
Weidmueller 1180290000
TOS 120VAC/48VDC 0.5A RC
On Request. Please send us an email to inquire the price and avaliability.
"ucnguBrctvdgcxgt0eqo"
Description
Technical parameters
| Type: | TOS 120VAC/48VDC 0.5A RC |
| Order No.: | 1180290000 |
| Version: | TERMOPTO, solid-state relais, 1 NO contact (Transistor), Rated control voltage: 120 V AC ±20 % , Rated switching voltage: 5...48 V DC, Continuous current: 500 mA, Screw connection |
| GTIN (EAN): | 4032248100057 |
| Qty.: | 10 pc(s). |
| Width: | 6.1 mm |
| Width (inches): | 0.24 inch |
| Height: | 74.4 mm |
| Height (inches): | 2.929 inch |
| Depth: | 55 mm |
| Depth (inches): | 2.165 inch |
| Net weight: | 20.4 g |
| Operating temperature, max.: | 60 °C |
| Operating temperature, min.: | -20 °C |
| Storage temperature, max.: | 80 °C |
| Storage temperature, min.: | -40 °C |
| Operating temperature: | -20 °C...60 °C |
| Storage temperature: | -40 °C...80 °C |
| MTTF: | 2,500 Years |
| REACH SVHC: | Lead 7439-92-1 |
| Rated control voltage: | 120 V AC ±20 % |
| Nominal control current: | 6.4 mA AC |
| Power rating: | ≤ 0.61 VA |
| Status indicator: | Green LED |
| Protective circuit: | RC element, Rectifier |
| Rated switching voltage: | 5...48 V DC |
| Continuous current: | 500 mA |
| Load category: | DC1 |
| Switch-on delay: | < 12.6 ms |
| Switch-off delay: | < 20.8 ms |
| Voltage drop at max. load: | < 1 V |
| Leakage current: | < 10 µA |
| Short-circuit-proof: | No |
| Protective circuit, load side: | Diode circuit |
| max. switching frequency (AC control voltage): | 10 Hz |
| Contact type: | 1 NO contact (Transistor) |
| Rail: | TS 35 |
| Colour: | black |
| UL 94 flammability rating: | V-0 |
| Rated voltage: | 300 V |
| Pollution severity: | 2 |
| Surge voltage category: | III |
| Clearance and creepage distances for control side - load side: | > 3 mm |
| Impulse withstand voltage: | 4 kV (1.2/50 µs) |
| Protection degree: | IP20 |
| Standards: | DIN EN 50178, IEC 62314, UL508 |
| Certificate no. (cULus): | E223474 |
| Wire connection method: | Screw connection |
| Stripping length, rated connection: | 9 mm |
| Tightening torque, min.: | 0.4 Nm |
| Tightening torque, max.: | 0.6 Nm |
| Clamping range, rated connection: | 2.5 mm² |
| Clamping range, min.: | 0.5 mm² |
| Clamping range, max.: | 4 mm² |
| Wire connection cross section AWG, min.: | AWG 20 |
| Wire connection cross section AWG, max.: | AWG 12 |
| Wire cross-section, solid, min.: | 0.5 mm² |
| Wire cross-section, solid, max.: | 4 mm² |
| Wire connection cross-section, finely stranded, min.: | 0.5 mm² |
| Wire connection cross section, finely stranded, max.: | 2.5 mm² |
| Wire cross-section, finely stranded, min. (AWG): | AWG 20 |
| Wire cross-section, finely stranded, max. (AWG): | AWG 12 |
| Wire connection cross-section, finely stranded with wire-end ferrules DIN 46228/4, min.: | 0.5 mm² |
| Wire connection cross-section, finely stranded with wire-end ferrules DIN 46228/4, max.: | 1.5 mm² |
| Conductor cross-section, flexible, AEH (DIN 46228-1), min.: | 0.5 mm² |
| Conductor cross-section, flexible, AEH (DIN 46228-1), max.: | 1.5 mm² |
| Blade size: | 0.6 x 3.5 mm |
| ETIM 6.0: | EC001504 |
| ETIM 7.0: | EC001504 |
| eClass 9.0: | 27-37-16-04 |
| eClass 9.1: | 27-37-16-04 |
| eClass 10.0: | 27-37-16-04 |
| ROHS: | Conform |
| Type: | TOS 120VAC/48VDC 0.5A RC |
| Order No.: | 1180290000 |
| Version: | TERMOPTO, solid-state relais, 1 NO contact (Transistor), Rated control voltage: 120 V AC ±20 % , Rated switching voltage: 5...48 V DC, Continuous current: 500 mA, Screw connection |
| GTIN (EAN): | 4032248100057 |
| Qty.: | 10 pc(s). |
| Width: | 6.1 mm |
| Width (inches): | 0.24 inch |
| Height: | 74.4 mm |
| Height (inches): | 2.929 inch |
| Depth: | 55 mm |
| Depth (inches): | 2.165 inch |
| Net weight: | 20.4 g |
| Operating temperature, max.: | 60 °C |
| Operating temperature, min.: | -20 °C |
| Storage temperature, max.: | 80 °C |
| Storage temperature, min.: | -40 °C |
| Operating temperature: | -20 °C...60 °C |
| Storage temperature: | -40 °C...80 °C |
| MTTF: | 2,500 Years |
| REACH SVHC: | Lead 7439-92-1 |
| Rated control voltage: | 120 V AC ±20 % |
| Nominal control current: | 6.4 mA AC |
| Power rating: | ≤ 0.61 VA |
| Status indicator: | Green LED |
| Protective circuit: | RC element, Rectifier |
| Rated switching voltage: | 5...48 V DC |
| Continuous current: | 500 mA |
| Load category: | DC1 |
| Switch-on delay: | < 12.6 ms |
| Switch-off delay: | < 20.8 ms |
| Voltage drop at max. load: | < 1 V |
| Leakage current: | < 10 µA |
| Short-circuit-proof: | No |
| Protective circuit, load side: | Diode circuit |
| max. switching frequency (AC control voltage): | 10 Hz |
| Contact type: | 1 NO contact (Transistor) |
| Rail: | TS 35 |
| Colour: | black |
| UL 94 flammability rating: | V-0 |
| Rated voltage: | 300 V |
| Pollution severity: | 2 |
| Surge voltage category: | III |
| Clearance and creepage distances for control side - load side: | > 3 mm |
| Impulse withstand voltage: | 4 kV (1.2/50 µs) |
| Protection degree: | IP20 |
| Standards: | DIN EN 50178, IEC 62314, UL508 |
| Certificate no. (cULus): | E223474 |
| Wire connection method: | Screw connection |
| Stripping length, rated connection: | 9 mm |
| Tightening torque, min.: | 0.4 Nm |
| Tightening torque, max.: | 0.6 Nm |
| Clamping range, rated connection: | 2.5 mm² |
| Clamping range, min.: | 0.5 mm² |
| Clamping range, max.: | 4 mm² |
| Wire connection cross section AWG, min.: | AWG 20 |
| Wire connection cross section AWG, max.: | AWG 12 |
| Wire cross-section, solid, min.: | 0.5 mm² |
| Wire cross-section, solid, max.: | 4 mm² |
| Wire connection cross-section, finely stranded, min.: | 0.5 mm² |
| Wire connection cross section, finely stranded, max.: | 2.5 mm² |
| Wire cross-section, finely stranded, min. (AWG): | AWG 20 |
| Wire cross-section, finely stranded, max. (AWG): | AWG 12 |
| Wire connection cross-section, finely stranded with wire-end ferrules DIN 46228/4, min.: | 0.5 mm² |
| Wire connection cross-section, finely stranded with wire-end ferrules DIN 46228/4, max.: | 1.5 mm² |
| Conductor cross-section, flexible, AEH (DIN 46228-1), min.: | 0.5 mm² |
| Conductor cross-section, flexible, AEH (DIN 46228-1), max.: | 1.5 mm² |
| Blade size: | 0.6 x 3.5 mm |
| ETIM 6.0: | EC001504 |
| ETIM 7.0: | EC001504 |
| eClass 9.0: | 27-37-16-04 |
| eClass 9.1: | 27-37-16-04 |
| eClass 10.0: | 27-37-16-04 |
| ROHS: | Conform |
Logistic parameters
| ECCN: | |
| Country of Origin: | |
| EAN: | |
| Weight: | 0.02 kg |
| Length: | 0.00 m |
| Width: | 0.00 m |
| Height: | 0.00 m |
