Product
Weidmueller
1123520000
TRS 60VUC 2CO
Request a Quote
Image copyright: Weidmueller
Weidmueller 1123520000
TRS 60VUC 2CO
On Request. Please send us an email to inquire the price and avaliability.
"ucnguBrctvdgcxgt0eqo"
Description
Technical parameters
| Type: | TRS 60VUC 2CO |
| Order No.: | 1123520000 |
| Version: | TERMSERIES, Relay module, Number of contacts: 2, CO contact AgNi, Rated control voltage: 60 V UC ±10 %, Continuous current: 8 A, Screw connection |
| GTIN (EAN): | 4032248905911 |
| Qty.: | 10 pc(s). |
| Width: | 12.8 mm |
| Width (inches): | 0.504 inch |
| Height: | 89.6 mm |
| Height (inches): | 3.528 inch |
| Depth: | 87.8 mm |
| Depth (inches): | 3.457 inch |
| Net weight: | 57 g |
| Operating temperature, max.: | 60 °C |
| Operating temperature, min.: | -40 °C |
| Storage temperature, max.: | 85 °C |
| Storage temperature, min.: | -40 °C |
| Operating temperature: | -40 °C...60 °C |
| Storage temperature: | -40 °C...85 °C |
| REACH SVHC: | Lead 7439-92-1 |
| Ambient temperature (operational), max.: | 60 °C |
| Connection cross-section AWG, min.: | AWG 26 |
| Connection cross-section AWG, max.: | AWG 14 |
| Type of conductor: | rigid copper conductor, flexible copper conductor |
| Tightening torque, max.: | 0.4 Nm |
| Pollution severity level: | 2 |
| Altitude: | ≤ 2000 m, above sea level |
| Rated control voltage: | 60 V UC ± 10 % |
| Rated current AC: | 8.3 mA |
| Rated current DC: | 6.0 mA |
| Power rating: | 360 mW, 500 mVA |
| Status indicator: | Green LED |
| Protective circuit: | Rectifier |
| Coil voltage of the replacement relay deviating from the rated control voltage: | Yes |
| Coil voltage of the replacement relay: | 60 V DC |
| Rated switching voltage: | 250 V AC |
| Max. switching voltage, AC: | 250 V |
| Max. switching voltage, DC: | 250 V |
| Continuous current: | 8 A |
| Inrush current: | 15 A / 4 s |
| AC switching capacity (resistive), max.: | 2000 VA |
| DC switching capacity (resistive), max.: | 192 W @ 24 V |
| Switch-on delay: | ≤ 11 ms |
| Switch-off delay: | ≤ 7 ms |
| Min. switching power: | 1 mA @ 24 V, 10 mA @ 10 V, 100 mA @ 5 V |
| Max. switching frequency at rated load: | 0.1 Hz |
| Contact type: | 2 CO contact (AgNi) |
| Rail: | TS 35 |
| Test button: | No |
| Mechanical switch position indicator: | No |
| Colour: | black |
| UL 94 flammability rating: | V-0 |
| Rated voltage: | 300 V |
| Surge voltage category: | III |
| Pollution severity: | 2 |
| Protection degree: | IP20 |
| Type of isolation at input and output: | reinforced insulation |
| Creepage and clearance distance input – output: | ≥ 6 mm |
| Type of isolation at neighbouring contacts: | Basic insulation |
| Impulse withstand voltage: | 6 kV (1.2/50 µs) |
| Standards: | EN 50178, EN 55011, EN 61000-6-1, 2, 4 |
| Certificate No. (DNVGL): | TAA00001E5 |
| Certificate no. (cULus): | E141197 |
| Wire connection method: | Screw connection |
| Stripping length, rated connection: | 8 mm |
| Tightening torque, max.: | 0.4 Nm |
| Clamping range, rated connection: | 1.5 mm² |
| Clamping range, min.: | 0.14 mm² |
| Clamping range, max.: | 2.5 mm² |
| Wire connection cross section AWG, min.: | AWG 26 |
| Wire connection cross section AWG, max.: | AWG 14 |
| Wire cross-section, solid, min.: | 0.14 mm² |
| Wire cross-section, solid, max.: | 2.5 mm² |
| Wire connection cross-section, finely stranded, min.: | 0.14 mm² |
| Wire connection cross section, finely stranded, max.: | 2.5 mm² |
| Wire cross-section, finely stranded, min. (AWG): | AWG 26 |
| Wire cross-section, finely stranded, max. (AWG): | AWG 14 |
| Wire connection cross-section, finely stranded with wire-end ferrules DIN 46228/4, min.: | 0.25 mm² |
| Wire connection cross-section, finely stranded with wire-end ferrules DIN 46228/4, max.: | 2.5 mm² |
| Conductor cross-section, flexible, AEH (DIN 46228-1), min.: | 0.25 mm² |
| Conductor cross-section, flexible, AEH (DIN 46228-1), max.: | 2.5 mm² |
| Wire connection cross section, finely stranded, two clampable wires, min.: | 0.5 mm² |
| Wire cross-section, finely stranded, two clampable wires, max.: | 1 mm² |
| Twin wire-end ferrules, min.: | 0.5 mm² |
| Twin wire-end ferrules, max.: | 1 mm² |
| Blade size: | size PH0 |
| Gauge to IEC 60947-1: | A1, B1 |
| ETIM 6.0: | EC001437 |
| ETIM 7.0: | EC001437 |
| eClass 9.0: | 27-37-16-01 |
| eClass 9.1: | 27-37-16-01 |
| eClass 10.0: | 27-37-16-01 |
| ROHS: | Conform |
| Type: | TRS 60VUC 2CO |
| Order No.: | 1123520000 |
| Version: | TERMSERIES, Relay module, Number of contacts: 2, CO contact AgNi, Rated control voltage: 60 V UC ±10 %, Continuous current: 8 A, Screw connection |
| GTIN (EAN): | 4032248905911 |
| Qty.: | 10 pc(s). |
| Width: | 12.8 mm |
| Width (inches): | 0.504 inch |
| Height: | 89.6 mm |
| Height (inches): | 3.528 inch |
| Depth: | 87.8 mm |
| Depth (inches): | 3.457 inch |
| Net weight: | 57 g |
| Operating temperature, max.: | 60 °C |
| Operating temperature, min.: | -40 °C |
| Storage temperature, max.: | 85 °C |
| Storage temperature, min.: | -40 °C |
| Operating temperature: | -40 °C...60 °C |
| Storage temperature: | -40 °C...85 °C |
| REACH SVHC: | Lead 7439-92-1 |
| Ambient temperature (operational), max.: | 60 °C |
| Connection cross-section AWG, min.: | AWG 26 |
| Connection cross-section AWG, max.: | AWG 14 |
| Type of conductor: | rigid copper conductor, flexible copper conductor |
| Tightening torque, max.: | 0.4 Nm |
| Pollution severity level: | 2 |
| Altitude: | ≤ 2000 m, above sea level |
| Rated control voltage: | 60 V UC ± 10 % |
| Rated current AC: | 8.3 mA |
| Rated current DC: | 6.0 mA |
| Power rating: | 360 mW, 500 mVA |
| Status indicator: | Green LED |
| Protective circuit: | Rectifier |
| Coil voltage of the replacement relay deviating from the rated control voltage: | Yes |
| Coil voltage of the replacement relay: | 60 V DC |
| Rated switching voltage: | 250 V AC |
| Max. switching voltage, AC: | 250 V |
| Max. switching voltage, DC: | 250 V |
| Continuous current: | 8 A |
| Inrush current: | 15 A / 4 s |
| AC switching capacity (resistive), max.: | 2000 VA |
| DC switching capacity (resistive), max.: | 192 W @ 24 V |
| Switch-on delay: | ≤ 11 ms |
| Switch-off delay: | ≤ 7 ms |
| Min. switching power: | 1 mA @ 24 V, 10 mA @ 10 V, 100 mA @ 5 V |
| Max. switching frequency at rated load: | 0.1 Hz |
| Contact type: | 2 CO contact (AgNi) |
| Rail: | TS 35 |
| Test button: | No |
| Mechanical switch position indicator: | No |
| Colour: | black |
| UL 94 flammability rating: | V-0 |
| Rated voltage: | 300 V |
| Surge voltage category: | III |
| Pollution severity: | 2 |
| Protection degree: | IP20 |
| Type of isolation at input and output: | reinforced insulation |
| Creepage and clearance distance input – output: | ≥ 6 mm |
| Type of isolation at neighbouring contacts: | Basic insulation |
| Impulse withstand voltage: | 6 kV (1.2/50 µs) |
| Standards: | EN 50178, EN 55011, EN 61000-6-1, 2, 4 |
| Certificate No. (DNVGL): | TAA00001E5 |
| Certificate no. (cULus): | E141197 |
| Wire connection method: | Screw connection |
| Stripping length, rated connection: | 8 mm |
| Tightening torque, max.: | 0.4 Nm |
| Clamping range, rated connection: | 1.5 mm² |
| Clamping range, min.: | 0.14 mm² |
| Clamping range, max.: | 2.5 mm² |
| Wire connection cross section AWG, min.: | AWG 26 |
| Wire connection cross section AWG, max.: | AWG 14 |
| Wire cross-section, solid, min.: | 0.14 mm² |
| Wire cross-section, solid, max.: | 2.5 mm² |
| Wire connection cross-section, finely stranded, min.: | 0.14 mm² |
| Wire connection cross section, finely stranded, max.: | 2.5 mm² |
| Wire cross-section, finely stranded, min. (AWG): | AWG 26 |
| Wire cross-section, finely stranded, max. (AWG): | AWG 14 |
| Wire connection cross-section, finely stranded with wire-end ferrules DIN 46228/4, min.: | 0.25 mm² |
| Wire connection cross-section, finely stranded with wire-end ferrules DIN 46228/4, max.: | 2.5 mm² |
| Conductor cross-section, flexible, AEH (DIN 46228-1), min.: | 0.25 mm² |
| Conductor cross-section, flexible, AEH (DIN 46228-1), max.: | 2.5 mm² |
| Wire connection cross section, finely stranded, two clampable wires, min.: | 0.5 mm² |
| Wire cross-section, finely stranded, two clampable wires, max.: | 1 mm² |
| Twin wire-end ferrules, min.: | 0.5 mm² |
| Twin wire-end ferrules, max.: | 1 mm² |
| Blade size: | size PH0 |
| Gauge to IEC 60947-1: | A1, B1 |
| ETIM 6.0: | EC001437 |
| ETIM 7.0: | EC001437 |
| eClass 9.0: | 27-37-16-01 |
| eClass 9.1: | 27-37-16-01 |
| eClass 10.0: | 27-37-16-01 |
| ROHS: | Conform |
Logistic parameters
| ECCN: | |
| Country of Origin: | |
| EAN: | |
| Weight: | 0.062 kg |
| Length: | 0.00 m |
| Width: | 0.00 m |
| Height: | 0.00 m |
