Wago 2857-535/000-001

Temperature signal conditioner; Configuration via software; Supply voltage: 24 VDC

Description

A relay with changeover contact reacts to configured measurement range limits (on/off switching delay and threshold value switch function can be configured with up to two threshold values). Configurable Pt factor. Adjustable software filter. Simulation of input/output response via interface configuration display. Input of customer-specific sensors via the interface configuration software. Safe 3-way isolation with 3 kV test voltage per EN 61010-1. Output-end RS-485 interface with Modbus protocol. Terminating resistor can be adjusted at the output. Adjustable transfer characteristic
