Product
Pilz
774140
PZE 9 24VAC 8n/o 1n/c
Request a Quote
Image copyright: Pilz
Pilz 774140
PZE 9 24VAC 8n/o 1n/c
Contact expansion Inputs: ability to detect shorts across, contacts Outputs: 8 N/O, 1 N/C UB 24 V AC, width: 90 mm, Contact block, for contact expansion + amplification in connection with, safety-related control components.
On Request. Please send us an email to inquire the price and avaliability.
"ucnguBrctvdgcxgt0eqo"
Description
Technical parameters
| Certifications:: | CE, cULus Listed, EAC (Eurasian), TÜV, CCC |
| Application options:: | Instantaneous contact expansion |
| Operating modes:: | Single-channel, Dual-channel, Detection of shorts across contacts, without detection of shorts across contacts |
| Standards:: | EN 60204-1, EN 62061, EN ISO 13849-1, VDE 0113-1 |
| Supply voltage (V):: | 24,0 |
| Supply voltage type:: | AC |
| Terminal style:: | fixed |
| Terminal type:: | Screw terminal |
| Number of instantaneous safety contacts:: | 8 |
| Number of delayed safety contacts:: | 0 |
| Number of auxiliary contacts:: | 1 |
| Max. current at DC13 I (6 cycles/min):: | 7.0 A |
| Voltage at AC15:: | 230 V |
| Width dimension:: | 90.0 mm |
| Height dimension:: | 87.0 mm |
| Depth dimension:: | 121.0 mm |
| Gross weight:: | 610 g |
| Net weight:: | 600 g |
| Ambient temperature:: | -10 - 55 °C |
Logistic parameters
| ECCN: | |
| Country of Origin: | |
| EAN: | |
| Weight: | 0.00 kg |
| Length: | 0.00 m |
| Width: | 0.00 m |
| Height: | 0.00 m |
