UT98A123
Sensor ultrasonic, diffuse-reflection sensor, 30x31x65mm, Sn: 100-1000, 15-30V DC, 0-10V, Connector M12, IP67, Plastic, Teach-In, ultrasonic cone 10° Axial
Ultrasonic sensors. Ultrasonic sensors are non-contact and wear-free position switches which can also be used under rough environmental conditions. A key advantage of these devices lies in the fact that the material and the surface characteristics of the objects to be detected can be almost anything. Solids, liquids, grainy materials and powdery materials can be identified without the shape or the color of the object having any influence to the measured result. In addition, the ability to detect transparent materials such as films and fluids is of particular importance. The shape and color of the objects do not influence the result of the detection. The capability to detect transparent films or liquids is also of special importance. Ultrasonic sensors are used for distance measurement (e.g. detection of diameters, loop control), for fill level detection (e.g. silo detection), for positioning and presence detection (e.g. glass pane positioning, film tear check, glass bottle detection)
Design: | Cuboid |
Ambient temperature: | -10 - 60°C |
Sensor width: | 65mm |
Sensor length: | 31mm |
Housing material: | Plastic |
Degree of protection (IP): | IP67 |
Sensor height: | 30mm |
Voltage type: | DC |
Type of analog output: | 0 V ... 10 V |
Setting procedure: | Teach-In |
Relative repeat accuracy: | 0.1% |
Short-circuit protection: | yes |
Measuring range length: | 100 - 1000mm |
Response time: | 80ms |
Carrier frequency: | 240kHz |
Switching frequency: | 12.5Hz |
Type of electrical connection: | Connector M12 |
No-load current: | 35mA |
Supply voltage: | 15 - 30V |
Temperature drift: | 2% |
Reverse polarity protection: | yes |
Sound cone (angle of beam spread): | 10° |
Sound outlet: | Axial |
eClass 7.0: | 27270804 |
eClass 7.1: | 27270804 |
eClass 8.0: | 27270804 |
eClass 9.0: | 27270804 |
eClass 9.1: | 27270804 |
ETIM-6.0: | EC001846 |
ETIM-7.0: | EC001846 |
IPF Product Group: | 700 |
shipping weight: | 0.07kg |
packaging dimensions: | 43.0mm x 43.0mm x 105.0mm |
customs tariff number: | 85365019 |
