Product
IPF
PE280146
Request a Quote
Image copyright: IPF
IPF PE280146
On Request. Please send us an email to inquire the price and avaliability.
"ucnguBrctvdgcxgt0eqo"
Description
Technical parameters
| Version: | Line sensor receiver |
| Housing material: | Aluminum |
| Ambient temperature: | -10 - 50°C |
| Degree of protection (IP): | IP54 |
| Sensor height: | 98mm |
| Number of configurable switching outputs: | 3 |
| Field height: | 28mm |
| Design: | Cuboid |
| Housing coating: | Anodized |
| Material of optical surface: | Glass |
| Sensor width: | 20mm |
| Sensor length: | 70mm |
| Storage temperature: | -20 - 85°C |
| Voltage type: | DC |
| Type of input voltage: | DC |
| Type of analog output: | 0 V ... 10 V / 4 mA ... 20 mA |
| Type of switching output: | PNP/NPN |
| Equipment protection class: | Protection class 3 |
| Setting procedure: | Parameterization |
| Measuring range: | 2m |
| Rated switching current: | 100mA |
| Scanning function: | Light-/dark-on mode |
| Reverse polarity protection: | yes |
| Connection to amplifier: | no |
| Measurement frequency: | 800Hz |
| Type of plug-in contact, communication interface: | Female (socket) |
| Type of communication interface, transmitter + receiver: | Connector M9 |
| Type of plug-in contact, communication interface: | Female (socket) |
| Number of pins: | 8 |
| Switching frequency: | 800Hz |
| Type of electrical connection: | Connector M9 |
| Type of switching function: | Push-pull |
| Operating voltage: | 21.6 - 26.4V |
| No-load current: | 200mA |
| Relative repeat accuracy: | 2µm |
| Short-circuit protection: | yes |
| Rated switching distance: | 2000mm |
| Residual ripple: | 10% |
| Laser power: | 0.4mW |
| Number of pins of the communication interface: | 4 |
| Type of communication interface: | Connector M5 |
| Number of pins of the communication interface, transmitter + receiver: | 4 |
| Scope of delivery of the one-way system: | Receiver |
| Laser class: | 1 |
| Light source: | Laser diode, red light |
| Resolution: | 2µm |
| Filter: | Interference filter |
| Laser protection class: | Class 1 |
| Wavelength of the sensor: | 670nm |
| Light beam form: | Line |
| Line sensor: | yes |
| eClass 7.0: | 27270901 |
| eClass 7.1: | 27270901 |
| eClass 8.0: | 27270901 |
| eClass 9.0: | 27270901 |
| eClass 9.1: | 27270901 |
| ETIM-6.0: | EC002716 |
| ETIM-7.0: | EC002716 |
| IPF Product Group: | 165 |
| shipping weight: | 0.25kg |
| packaging dimensions: | 99.0mm x 60mm x 160mm |
| customs tariff number: | 85365019 |
Logistic parameters
| ECCN: | |
| Country of Origin: | |
| EAN: | |
| Weight: | 0.00 kg |
| Length: | 0.00 m |
| Width: | 0.00 m |
| Height: | 0.00 m |
