OT370505
Cable length: | 5m |
Housing material: | Stainless steel 1.4404 |
Ambient temperature: | -30 - 70°C |
Degree of protection (IP): | IP67 / IP69k |
Sensor height: | 35.5mm |
Storage temperature: | -30 - 70°C |
Design: | Cuboid |
Number of cores: | 4 |
Material of optical surface: | PMMA |
Sensor width: | 14mm |
Sensor length: | 25mm |
Voltage type: | DC |
Adjustment range: | 20 - 100mm |
Type of electrical connection: | Cable |
Type of switching function: | Push-pull |
Setting procedure: | Manual adjustment |
Rated switching current: | 100mA |
Max. switching distance: | 100mm |
Rated switching distance: | 100mm |
Response time: | 0.5ms |
Voltage drop: | 2V |
Decay time: | 0.5ms |
Number of switching outputs: | 2 |
Switching frequency: | 1000Hz |
Type of switching output: | PNP/NPN |
Operating voltage: | 10 - 30V |
No-load current: | 15mA |
Short-circuit protection: | yes |
Scanning function: | Light-/dark-on mode |
Sensing range: | 20 - 100mm |
Residual ripple: | 15% |
Readiness delay: | 300ms |
Light source: | Polarity free red light |
Wavelength of the sensor: | 620nm |
Light beam form: | Line |
Light spot: | 120mm² |
Triangulation: | Background suppression |
Background suppression: | yes |
eClass 7.0: | 27270904 |
eClass 7.1: | 27270904 |
eClass 8.0: | 27270904 |
eClass 9.0: | 27270904 |
eClass 9.1: | 27270904 |
ETIM-6.0: | EC002719 |
ETIM-7.0: | EC002719 |
IPF Product Group: | 100 |
shipping weight: | 0.2kg |
packaging dimensions: | 110mm x 45.0mm x 180mm |
customs tariff number: | 85365019 |
