Product
IPF
OI98A920
Request a Quote
Image copyright: IPF
IPF OI98A920
On Request. Please send us an email to inquire the price and avaliability.
"ucnguBrctvdgcxgt0eqo"
Description
Technical parameters
| Design: | Cuboid |
| Degree of protection (IP): | IP65 |
| Cable length of measuring head: | 1m |
| Housing material: | Stainless steel 1.4571 |
| Operating temperature of the measuring head: | -20 - 180°C |
| Voltage type: | DC |
| Measuring range: | -40 - 900°C |
| Type of electrical connection: | Clamp |
| Operating voltage: | 8 - 36V |
| No-load current: | 100mA |
| Infrared measurement: | yes |
| Temperature drift: | 0.05% |
| Type of alarm output: | PNP |
| Switching function of the alarm output: | EV006675 |
| Interface possible: | yes |
| Display: | Digital |
| Type of analog output: | 0 / 4 … 20 mA, 0 … 5 / 10 V |
| Type of switching function: | Normally open contact (NO) |
| Setting procedure: | Parameterization |
| Relative repeat accuracy: | 0.5% |
| Rated switching current: | 50mA |
| Response time: | 150ms |
| Response/decay time: | 100ms |
| Programmable via software: | yes |
| Data logging possible: | yes |
| Light spot diameter: | 7 - 36mm |
| Spectral sensitivity: | 8 - 14µm |
| Ratio (D:S): | 22:1 |
| eClass 7.0: | 27201120 |
| eClass 7.1: | 27201120 |
| eClass 8.0: | 27201120 |
| eClass 9.0: | 27201120 |
| eClass 9.1: | 27201120 |
| ETIM-6.0: | EC000601 |
| ETIM-7.0: | EC000601 |
| IPF Product Group: | 700 |
| shipping weight: | 0.66kg |
| packaging dimensions: | 145.0mm x 75.0mm x 215.0mm |
| customs tariff number: | 90251900 |
| Zolltarifnummer: | 90251900 |
Logistic parameters
| ECCN: | |
| Country of Origin: | |
| EAN: | |
| Weight: | 0.00 kg |
| Length: | 0.00 m |
| Width: | 0.00 m |
| Height: | 0.00 m |
