Article image OI810147

IPF OI810147

On Request. Please send us an email to inquire the price and avaliability.
"ucnguBrctvdgcxgt0eqo"

Description

Technical parameters

Design: Cylinder plain
Ambient temperature: -20 - 75°C
Sensor diameter: 60mm
Housing material: Stainless steel 1.4571
Degree of protection (IP): IP67
Voltage type: DC
Number of pins: 5
Switching frequency: 10Hz
Type of switching output: PNP
Operating voltage: 10 - 55V
No-load current: 15mA
Rated switching current: 400mA
Hysteresis: 5%
Display: None
Measuring range: 0 - 650°C
Type of electrical connection: Plug-in connection
Type of switching function: Normally open contact (NO)
Setting procedure: Manual adjustment
Infrared measurement: yes
Short-circuit protection: yes
eClass 7.0: 27201120
eClass 7.1: 27201120
eClass 8.0: 27201120
eClass 9.0: 27201120
eClass 9.1: 27201120
ETIM-6.0: EC000601
ETIM-7.0: EC000601
IPF Product Group: 103
shipping weight: 1.15kg
packaging dimensions: 138.0mm x 95.0mm x 210mm
customs tariff number: 90251900
