OE106070
Version: | Through-beam sensor receiver |
Housing material: | Plastic |
Material of optical surface: | Plastic |
Sensor diameter: | 10mm |
Shock resistance: | 30g |
Storage temperature: | -40 - 80°C |
Design: | Cylinder plain |
Ambient temperature: | -25 - 60°C |
Degree of protection (IP): | IP67 |
Sensor length: | 47.3mm |
Vibration resistance: | 55Hz |
Type of input voltage: | DC |
Type of electrical connection: | Connector M8 |
Connection to amplifier: | yes |
Switching frequency: | 15Hz |
Max. switching distance: | 70m |
Scope of delivery of the one-way system: | Receiver |
Angle of beam spread: | 25° |
Wavelength of the sensor: | 880nm |
Light source: | Infrared light |
Light beam form: | Point |
eClass 7.0: | 27270901 |
eClass 7.1: | 27270901 |
eClass 8.0: | 27270901 |
eClass 9.0: | 27270901 |
eClass 9.1: | 27270901 |
ETIM-6.0: | EC002716 |
ETIM-7.0: | EC002716 |
IPF Product Group: | 101 |
shipping weight: | 0.02kg |
packaging dimensions: | 75.0mm x 17.0mm x 95.0mm |
customs tariff number: | 85365019 |
ECCN: | |
Country of Origin: | |
EAN: | |
Weight: | 0.00 kg |
Length: | 0.00 m |
Width: | 0.00 m |
Height: | 0.00 m |
