MC120200
Thread length: | 55mm |
Design: | Cylinder, screw-thread |
Number of cores: | 3 |
Thread size, metric: | 12 |
Material of cable sheath: | PUR (Polyurethane) |
Sensor diameter: | 12mm |
Cable length: | 2m |
Housing material: | Stainless steel 1.4305 |
Ambient temperature: | -25 - 70°C |
Thread pitch: | 1mm |
Degree of protection (IP): | IP67 |
Sensor length: | 69mm |
Voltage type: | DC |
Number of switching outputs: | 1 |
Switching distance: | 40mm |
Type of switching output: | PNP |
Operating voltage: | 8 - 30V |
Cross/short circuit identification possible: | no |
Short-circuit protection: | yes |
Hysteresis: | 6mm |
Magnetic sensitivity: | 2.8mT |
Number of pins: | 3 |
Switching frequency: | 1000Hz |
Type of electrical connection: | Cable |
Type of switching function: | Normally closed contact |
No-load current: | 20mA |
Rated switching current: | 200mA |
Reverse polarity protection: | yes |
Voltage drop: | 2V |
eClass 7.0: | 27270105 |
eClass 7.1: | 27270105 |
eClass 8.0: | 27270105 |
eClass 9.0: | 27270105 |
eClass 9.1: | 27270105 |
ETIM-6.0: | EC002544 |
ETIM-7.0: | EC002544 |
IPF Product Group: | 230 |
shipping weight: | 0.08kg |
packaging dimensions: | 77.0mm x 25.0mm x 123.0mm |
customs tariff number: | 85365019 |
