IPF
LT100101
IPF LT100101
Fiber optic diffuse-reflection sensor, 1m, head: Stainless steel 25long Ø1.5 Ø6, Light exit Axial, conductor: Glassfiber+Silicone, end piece: M18x1 Brass, Sn: 10, -40-180°C, IP67
Description
Fiber optic sensors. Fiber optics in combination with the appropriate fiber optic amplifier function as contactless and wear-free position switches that can also be used in harsh environmental conditions. They detect objects independent of their characteristics (e.g., shape, color, surface structure, material). Because the ends and heads of the fiber optics have small dimensions and the fiber optics are flexible, very elegant solutions can be created for detecting objects in places that are difficult to access. Fiber optics can be used without special precautions in potentially explosive areas and in zones with electrical and/or magnetic fields (high-voltage installations, electrical welding equipment) as their function is not thereby affected. Fiber optics are available in versions for implementing the function as through-beam sensor or diffuse reflection sensor.
Technical parameters
| Version: | Reflection sensor |
| Fiber diameter: | 1mm |
| Number of fibers: | 1 |
| Fiber optics core material: | Glass |
| Sheathing material: | Silicone |
| Sensing head diameter: | 1.5mm |
| End piece diameter: | 20mm |
| End piece thread pitch: | 1mm |
| Fiber optic with small bending radius: | no |
| Bending radius (fixed): | 15mm |
| Sensing head diameter 1: | 1.5 |
| Sensing head material: | Stainless steel |
| Overall length: | 1000mm |
| Design: | Cylinder plain |
| Ambient temperature: | -40 - 180°C |
| Degree of protection (IP): | IP67 |
| End piece length: | 28mm |
| Metric thread size of end piece: | 18mm |
| Bendable: | no |
| Fiber optic with bendable head: | no |
| Bending radius (flexible): | 30mm |
| Fiber optic cable diameter: | 4.2 |
| Sensing head diameter 2: | 6 |
| End piece material: | Brass |
| Short-circuit protection: | no |
| Reverse polarity protection: | no |
| Bending angle of the sensing head: | 0° |
| Max. switching distance: | 10mm |
| Sensing head length: | 25mm |
| Light exit: | Axial |
| Nominal operating distance: | 10mm |
| Fiber optic with linear light beam: | no |
| Fiber optic for attachment optics: | no |
| Fiber optic with coaxial structure: | no |
| eClass 7.0: | 27270905 |
| eClass 7.1: | 27270905 |
| eClass 8.0: | 27270905 |
| eClass 9.0: | 27270905 |
| eClass 9.1: | 27270905 |
| ETIM-6.0: | EC002651 |
| ETIM-7.0: | EC002651 |
| IPF Product Group: | 150 |
| shipping weight: | 0.06kg |
| packaging dimensions: | 77.0mm x 25.0mm x 123.0mm |
| customs tariff number: | 90011090 |
| Zolltarifnummer: | 90011090 |
