LS102911
Version: | Through-beam sensors |
Fiber diameter: | 2.3mm |
Number of fibers: | 2 |
Fiber optics core material: | Glass |
End piece length: | 36mm |
Metric thread size of end piece: | 12mm |
Bendable: | no |
Fiber optic with bendable head: | no |
Fiber optic cable diameter, transmitter end: | 6.7 |
Sensing head diameter 1: | 4 |
Sensing head material: | Stainless steel |
Overall length: | 1000mm |
Design: | Cylinder plain |
Ambient temperature: | -40 - 300°C |
Sheathing material: | Stainless steel |
Sensing head diameter: | 4mm |
End piece diameter: | 14mm |
End piece thread pitch: | 1mm |
Fiber optic with small bending radius: | no |
Sensing head diameter 2: | 8 |
End piece material: | Brass |
Short-circuit protection: | no |
Sensing head length: | 37mm |
Light exit: | Axial |
Reverse polarity protection: | no |
Bending angle of the sensing head: | 90° |
Bending section of the sensing head: | 0mm |
Fiber optic for attachment optics: | no |
Fiber optic with coaxial structure: | no |
Fiber optic with linear light beam: | no |
eClass 7.0: | 27270905 |
eClass 7.1: | 27270905 |
eClass 8.0: | 27270905 |
eClass 9.0: | 27270905 |
eClass 9.1: | 27270905 |
ETIM-6.0: | EC002651 |
ETIM-7.0: | EC002651 |
IPF Product Group: | 150 |
shipping weight: | 0.21kg |
packaging dimensions: | 124.0mm x 28.0mm x 149.0mm |
customs tariff number: | 90011090 |
Verpackungsmaße: | 124.0mm x 28.0mm x 149.0mm |
Zolltarifnummer: | 90011090 |
