KN204187
Sensor capacitive, Ø20mm 78long, Non-flush, Sn: 1-15, Two-wire NO, Cable, IP67, PBT
Capacitive proximity switches are contact-free sensors. They detect metallic and non-metallic objects, regardless of whether they move or not. The achievable sensing range of the devices depends on the object material, its dimensions and the response sensitivity, which is set via a potentiometer. The vibration-resistant sensors can be approached laterally or frontally. Capacitive proximity switches are used for presence detection (e.g. sealing detection), positioning (e.g. PET bottles), counting (e.g. plastic caps), level detection (e.g. lubricant) or distance measurements (e.g. thickness measurement) of solid and liquid materials.
Design: | Cylinder plain |
Ambient temperature: | -25 - 70°C |
Degree of protection (IP): | IP67 |
Sensor diameter: | 20mm |
Housing material: | PBT |
Mechanical mounting condition for sensor: | Non-flush |
Pressure-proof: | no |
Sensor length: | 78mm |
Voltage type: | AC |
Switching distance: | 1 - 15mm |
Type of electrical connection: | Cable |
Type of switching function: | Normally open contact |
Cascadable: | no |
Switching distance: | 10mm |
Type of switching output: | Two-wire |
Rated switching current: | 400mA |
eClass 7.0: | 27270102 |
eClass 7.1: | 27270102 |
eClass 8.0: | 27270102 |
eClass 9.0: | 27270102 |
eClass 9.1: | 27270102 |
ETIM-6.0: | EC002715 |
ETIM-7.0: | EC002715 |
IPF Product Group: | 243 |
shipping weight: | 0.16kg |
packaging dimensions: | 76.0mm x 50mm x 121.0mm |
customs tariff number: | 85365080 |
