Product
IPF
IY4401A0
Request a Quote
Image copyright: IPF
IPF IY4401A0
On Request. Please send us an email to inquire the price and avaliability.
"ucnguBrctvdgcxgt0eqo"
Description
Technical parameters
| Cable infeed: | Axial |
| Cable length: | 2m |
| Housing material: | Plastic ABS |
| Mechanical mounting condition for sensor: | Non-flush |
| Material of cable sheath: | PUR (Polyurethane) |
| Pressure-proof: | no |
| Design: | Ring-shaped |
| Ambient temperature: | -25 - 70°C |
| Active area material of sensor: | Plastic ABS |
| Ring diameter: | 44mm |
| Sensor length: | 124mm |
| Voltage type: | DC |
| Switching distance: | 44mm |
| Type of switching output: | PNP |
| Supply voltage: | 10 - 30V |
| Switching behavior of the output: | Static |
| Cascadable: | no |
| Type of electrical connection: | Cable |
| Type of switching function: | Normally open contact |
| Rated switching current: | 200mA |
| eClass 7.0: | 27270101 |
| eClass 7.1: | 27270101 |
| eClass 8.0: | 27270101 |
| eClass 9.0: | 27270101 |
| eClass 9.1: | 27270101 |
| ETIM-6.0: | EC002714 |
| ETIM-7.0: | EC002714 |
| IPF Product Group: | 211 |
| shipping weight: | 0.31kg |
| packaging dimensions: | 230mm x 61.0mm x 290mm |
| customs tariff number: | 85365019 |
Logistic parameters
| ECCN: | |
| Country of Origin: | |
| EAN: | |
| Weight: | 0.00 kg |
| Length: | 0.00 m |
| Width: | 0.00 m |
| Height: | 0.00 m |
