Article image IB08C587

IPF IB08C587

On Request. Please send us an email to inquire the price and avaliability.
"ucnguBrctvdgcxgt0eqo"

Description

Technical parameters

Cable infeed: Axial
Thread length: 45mm
Design: Cylinder, screw-thread
Housing coating: Nickel-plated
Ambient temperature: -25 - 100°C
Thread pitch: 1mm
Active area material of sensor: PBT
Degree of protection (IP): IP67
Sensor length: 45mm
Cable length: 5m
Housing material: Brass
Number of cores: 3
Thread size, metric: 8
Mechanical mounting condition for sensor: Flush
Material of cable sheath: PUR (Polyurethane)
Pressure-proof: no
Alignment of cable entry: Axial
Voltage type: DC
Switching frequency: 5000Hz
Type of electrical connection: Cable
Type of switching function: Normally open contact
Relative repeat accuracy: 5%
Rated switching current: 200mA
Residual ripple: 10%
Norm measuring plate: 8x8x1mm
Cascadable: no
Switching distance: 1.5mm
Type of switching output: PNP
No-load current: 13mA
Supply voltage: 10 - 30V
Hysteresis: 15%
Voltage drop: 2.4V
eClass 7.0: 27270101
eClass 7.1: 27270101
eClass 8.0: 27270101
eClass 9.0: 27270101
eClass 9.1: 27270101
ETIM-6.0: EC002714
ETIM-7.0: EC002714
IPF Product Group: 700
shipping weight: 0.08kg
packaging dimensions: 77.0mm x 25.0mm x 123.0mm
customs tariff number: 85365019
