AO000479
Housing material: | Aluminum |
Lens connection: | C-mount (1-32 UN 2A) |
Lens diameter: | 61 |
Material of optical surface: | Glass |
Image circle diameter: | 11mm |
Lens length: | 164.9mm |
Type of accessory: | Lens |
Distortion: | 0.1% |
Motor zoom: | no |
Magnification: | 0.243 |
Telecentricity: | 0.08° |
Lens type: | Bi-telecentric |
Focusable: | no |
Aperture number: | 8 |
Operating distance: | 102.5mm |
Depth of focus: | 11mm |
Resolution capacity: | Up to 2 megapixel |
eClass 7.0: | 27279205 |
eClass 7.1: | 27279205 |
eClass 8.0: | 27279205 |
eClass 9.0: | 27273603 |
eClass 9.1: | 27273603 |
ETIM-6.0: | EC001776 |
ETIM-7.0: | EC001776 |
IPF Product Group: | 914 |
shipping weight: | 0.69kg |
packaging dimensions: | 138.0mm x 95.0mm x 210mm |
customs tariff number: | 90021100 |
ECCN: | |
Country of Origin: | |
EAN: | |
Weight: | 0.00 kg |
Length: | 0.00 m |
Width: | 0.00 m |
Height: | 0.00 m |
