Product
IPF
AO000463
Request a Quote
Image copyright: IPF
IPF AO000463
On Request. Please send us an email to inquire the price and avaliability.
"ucnguBrctvdgcxgt0eqo"
Description
Technical parameters
| Width: | 34mm |
| Light head material: | Plastic |
| Design: | Cuboid |
| Housing material: | Aluminum |
| Degree of protection (IP): | IP67 |
| Height: | 34mm |
| Type of lamp stand: | Screw-on plate |
| Length: | 86mm |
| Ambient temperature: | 10 - 50°C |
| Front screen material: | Acrylic glass |
| Protection class: | III |
| Voltage type: | DC |
| Type of electrical connection: | Connector M8 |
| Rated operation current: | 55.00mA |
| Lamp power: | 1.08W |
| Number of pins: | 4 |
| Nominal supply voltage: | 24 - 24V |
| Color temperature: | 6500K |
| Lamp: | LED |
| With lamp: | yes |
| Light version: | Spotlight |
| Radiation angle: | 120° |
| Light source: | White light |
| Number of LEDs: | 16 |
| eClass 7.0: | 27310204 |
| eClass 7.1: | 27310204 |
| eClass 8.0: | 27310204 |
| eClass 9.0: | 27310204 |
| eClass 9.1: | 27310204 |
| ETIM-7.0: | EC000348 |
| IPF Product Group: | 915 |
| shipping weight: | 0.19kg |
| packaging dimensions: | 99.0mm x 60mm x 160mm |
| customs tariff number: | 94054099 |
Logistic parameters
| ECCN: | |
| Country of Origin: | |
| EAN: | |
| Weight: | 0.00 kg |
| Length: | 0.00 m |
| Width: | 0.00 m |
| Height: | 0.00 m |
