AO000153
Width: | 49.5mm |
Height: | 8.4mm |
Resistant to chemicals: | no |
Number of mounting holes: | 2 |
Ambient temperature: | -25 - 100°C |
Material of optical surface: | PMMA |
Bore diameter: | 4.5mm |
UV-resistant: | yes |
Shape: | Rectangular |
Length: | 122mm |
Material: | PMMA |
Mounting type: | Screw hole |
Degree of protection (IP): | IP67 |
With heater: | no |
Polarized: | yes |
eClass 7.0: | 27279203 |
eClass 7.1: | 27279203 |
eClass 8.0: | 27279203 |
eClass 9.0: | 27273601 |
eClass 9.1: | 27273601 |
ETIM-6.0: | EC002467 |
ETIM-7.0: | EC002467 |
IPF Product Group: | 900 |
shipping weight: | 0.04kg |
packaging dimensions: | 100mm x 9.0mm x 175.0mm |
customs tariff number: | 39269097 |
Zolltarifnummer: | 39269097 |
ECCN: | |
Country of Origin: | |
EAN: | |
Weight: | 0.00 kg |
Length: | 0.00 m |
Width: | 0.00 m |
Height: | 0.00 m |
