Product
Escha
8076000
YK-FK4M8-2AL-WAS3-1/1/P00
Request a Quote
Image copyright: Escha
Escha 8076000
YK-FK4M8-2AL-WAS3-1/1/P00
Y-splitter, M8 female, 4 poles, with cable outlet, M12 male, straight, 3 poles
On Request. Please send us an email to inquire the price and avaliability.
"ucnguBrctvdgcxgt0eqo"
Description
PVC-cable for measurement and control-, and sensor technology. Suitable for applications in dry areas on packaging machines, assembly- and conveyor technology. High flexibility with unstressed movement (conditional drag-chain application possible). Predestined for applications in food- and beverage industry.
Downloads
Technical parameters
| Exit: | female, M8, straight |
| Contact material: | Metal, CuZn, gold-plated |
| Jacket color: | GY, similar RAL7040 |
| Wire cross-section: | 3 x 0.34 mm² |
| Wire insulation material: | PVC |
| Wire colors: | BN, BU, BK |
| Number of pins: | 4 |
| Current load (at 40°C): | 4 |
| Temperature range (fixed): | -25°C...+80°C |
| Temperature range (repeated): | 0°C...+80°C |
| Rated voltage cable: | ≤300 V |
| Special features: | seawater resistant, recyclable, LABS free, RoHs compliant, acid- and alkali resistant, ozone resistant, UV resistant |
| Grip body material: | Plastic, TPU, BK |
| Mechanical life-cycle: | >100 mating cycles |
| Degree of pollution: | 3 |
Logistic parameters
| ECCN: | |
| Country of Origin: | Deutschland |
| EAN: | |
| Weight: | 0.00 kg |
| Length: | 0.00 m |
| Width: | 0.00 m |
| Height: | 0.00 m |
