Eaton 279401

NZM2-XTVDVR-0

Door coupling rotary handle, red-yellow, size 2

On Request. Please send us an email to inquire the price and avaliability.
"ucnguBrctvdgcxgt0eqo"

Description

EL-Nummer (Norway). 0004358972. Optional accessories for circuit-breaker series NZM offers a comprehensive portfolio of application possibilities for worldwide use. Modular functional groups make mounting flexible and simple. Note: Complete including rotary drive and coupling parts. For extremely narrow installations with special short extension shaft, cannot be combined with NZM...-XDZ additional handle. External warning plate/marking plate can be clipped on. Red-yellow for emergency switching off. Lockable on the handle on the switch using up to 3 padlocks. Lockable in 0 position on handle, lockable on the 0 position on the switch using up to 3 padlocks. With door interlock. Can be used for: NZM2(-4), PN2(-4), N(N/O)2(-4)

Logistic parameters

ECCN:
Country of Origin: DE
EAN:
Weight: 0.72 kg
Length: 0.00 m
Width: 0.00 m
Height: 0.00 m
