Eaton 138373
BBA-TP3/100-C
Connection terminal board 3, 35-150mm2, 90mm, compact
On Request. Please send us an email to inquire the price and avaliability.
"ucnguBrctvdgcxgt0eqo"
Description
Connection terminal board, 60-mm compact system, poles=3, screw terminals, terminal capacity=35 up to 150mm² or AWG2-MCM300 or 10x20x1 or 10x16x0.8, Ie=480A, width=90mm, can be used for rail 12x5/10, silicon free, chlorine free, self-extinguishing to UL 94, track resistance CTI 200, temperature resistant to 120 °C, the terminal can be removed for the connection of uncut conductors, passing through is not possible
Logistic parameters
| ECCN: | |
| Country of Origin: | DE |
| EAN: | |
| Weight: | 0.58 kg |
| Length: | 0.00 m |
| Width: | 0.00 m |
| Height: | 0.00 m |
