Eaton 025527

T0-4-15682/ST/SVB

Main switch, +steel enclosure, 6p+1N/O+1N/C, Ie=12A, handle red yellow, 0-1, 90°

Description

Main switch according to IEC/EN60947-3, size T0 in steel sheet enclosure, 690 V/20A, degree of protection Front IP55, with red rotary handle and yellow locking collar, lockable in O position with 3 padlocks, design general: insulating material-surface mounting enclosure , flush mounting, centre mounting, rear mounting IVS service distribution board mounting. The capable, robust, compact T cam switches are used in industry, handwork, and building services management. A variety of standard circuits are available for selection. Special customer-specific circuits are implemented as supplements. The possibilities are almost unlimited here. Comprehensive accessories complete the switch range and supplement application possibilities. All contacts are equipped with double interrupting contacts.
