Article image 208161

Di-soric 208161

MZET 9-25 POL-K-TSS

Cylinder Sensor

On Request. Please send us an email to inquire the price and avaliability.
"ucnguBrctvdgcxgt0eqo"

Description

To be inserted from above. Compact design. All-electronically vibration-resistant. High reproducibility

Downloads

Technical parameters

Cylinder groove: T-groove, to be inserted from above in the slot
Mounting: excentric
Maximum rating: 100 mA, short-circuit-proof, polarity-safe
Service voltage: 10 ... 30 V DC
No-load current: 10 mA
Switching output: pnp, NC, short circuit protected
Display: LED: yellow - output signal
Voltage drop: < 2,5 V
Switching frequency: 10000 Hz
Reproducibility: 0,2 mm
Ambient temperature, operation: -25 … +80 °C
Insulation voltage endurance: 500 V
Protection class: IP 67
Protection degree: III, operation on protective low voltage
Casing material: mounting excentric stainless steel
Material: PUR (Cable)
Connection: Cable, Connector, 0,3 m, M8
Connecting cable: TK ...

Logistic parameters

ECCN:
Country of Origin:
EAN:
Weight: 0.01 kg
Length: 0.00 m
Width: 0.00 m
Height: 0.00 m
