Article image 206720

Di-soric 206720

BE 1-A65/120-G0-K-BS

Barlight

On Request. Please send us an email to inquire the price and avaliability.
"ucnguBrctvdgcxgt0eqo"

Description

Very compact design. Homogenous luminous field. Cable outlet at the front or back side usable. Universal mounting possibility. Metal casing. High efficiency. Robust metal casing

Downloads

Technical parameters

Design: Barlight
Illuminated area: 65 mm
Light colour: Infrared, 850 nm
Emission angle FWHM: 120°
Illumination intensity: 1100 µW/cm² (0.1 m), 300 µW/cm² (0.2 m), 60 µW/cm² (0.5 m)
Service voltage: 24 V DC (Supply Class 2)
No-load current: 90 mA
Power: 2,2 W
Shock-/vibration load: 10 ... 55 Hz / 1,0 mm / 30 g
Inverse polarity protection: Yes
Ambient temperature, operation: 0 … +40 °C (permanent operation)
Protection class: IP 20
Risk group (DIN EN 62471): Free group
Casing material: Aluminium anodized
Connection: M12
Connecting cable: VK ...

Logistic parameters

ECCN:
Country of Origin:
EAN:
Weight: 0.09 kg
Length: 0.00 m
Width: 0.00 m
Height: 0.00 m
