Article image 203631

Di-soric 203631

MZET 28 PSK-K-TSSL

Cylinder Sensor

On Request. Please send us an email to inquire the price and avaliability.
"ucnguBrctvdgcxgt0eqo"

Description

To be inserted from above. Metal casing. Mechanically weld-proof. All-electronically. High reproducibility

Downloads

Technical parameters

Cylinder groove: T-groove, to be inserted from above in the slot
Mounting: Locknut, allen screw SW 1.5 mm
Maximum rating: 200 mA, short-circuit-proof, polarity-safe
Service voltage: 10 ... 30 V DC
No-load current: < 10 mA
Switching output: pnp, 200 mA, NO, short circuit protected
Display: LED: yellow - output signal
Voltage drop: < 2,0 V
Switching frequency: 1000 Hz
Reproducibility: < 0,1 mm
Ambient temperature, operation: -25 … +70 °C
Insulation voltage endurance: 500 V
Protection class: IP 68, (Device and cable), IP 67, (Connector)
Protection degree: III, operation on protective low voltage
Casing material: Die-cast zinc
Material: PUR (Cable)
Connection: Cable, Connector, 0,3 m, M8
Connecting cable: TK ...

Logistic parameters

ECCN:
Country of Origin:
EAN:
Weight: 0.02 kg
