Product
Di-soric
201488
ORV 41 K 2500 P3K-TSL
Request a Quote
Image copyright: Di-soric
Di-soric 201488
ORV 41 K 2500 P3K-TSL
Retroreflective Sensor
On Request. Please send us an email to inquire the price and avaliability.
"ucnguBrctvdgcxgt0eqo"
Description
Red light. Polarized filter. Sensitivity adjustable. High resolution. Light/dark switching. Compact design
Downloads
Technical parameters
| Operating principle: | Retroreflective sensor |
| Evaluation: | digital |
| Size: | 40 x 34 x 12 mm (Dimensions) |
| Design: | cuboid design |
| Emitted light: | Red, 660 nm, clocked, polarized |
| Operating distance: | 2500 mm |
| Service voltage: | 10 ... 35 V DC |
| No-load current: | < 30 mA |
| Sensitivity adjustment: | potentiometer |
| Referring reflector: | 100 x 100 mm |
| Switching output: | pnp, 200 mA, NO/NC |
| Switching hysteresis: | < 2 mm |
| Shock-/vibration load: | 10 ... 55 Hz / 1,0 mm / 30 g |
| Voltage drop: | < 2,0 V |
| Switching frequency: | 750 Hz |
| Response-/release time: | 1,0 ms / 2,0 ms |
| Ambient temperature, operation: | -10 … +60 °C |
| Ambient light immunity: | 50 kLx |
| Insulation voltage endurance: | 500 V |
| Protection class: | IP 67 |
| Protection degree: | III, operation on protective low voltage |
| Casing material: | polyester glass-fiber reinforced |
| Material: | plastic (Window) |
| Connection: | Connector, M8, 3-poled |
Logistic parameters
| ECCN: | |
| Country of Origin: | |
| EAN: | |
| Weight: | 0.03 kg |
| Length: | 0.00 m |
| Width: | 0.00 m |
| Height: | 0.00 m |
