LTS-1180L-101
620-200-575
Operating principle: | Diffuse |
Light source: | Laser class 2, red 660 nm |
Housing size [mm]: | M18 |
Sensitivity adjustment: | 3-turn potentiometer |
Polarity: | NPN |
Output: | Light-on + Dark-on |
Interface: | Standard output |
Connection: | M12 4-pin |
Supply voltage: | 10...36 VDC |
Switching frequency max. [Hz]: | 1000 |
Housing material: | Stainless steel V2A |
Temperature range: | -10...50 °C |
Enclosure rating (IP): | IP 67 |
ECCN: | |
Country of Origin: | |
EAN: | |
Weight: | 0.00 kg |
Length: | 0.00 m |
Width: | 0.00 m |
Height: | 0.00 m |
