Product
Contrinex
LFK-4040-103
620-400-029
Request a Quote
Image copyright: Contrinex
Contrinex LFK-4040-103
620-400-029
On Request. Please send us an email to inquire the price and avaliability.
"ucnguBrctvdgcxgt0eqo"
Description
Downloads
Technical parameters
| Operating principle: | Fiber amplifier |
| Light source: | LED, infrared 880 nm |
| Housing size [mm]: | 40 x 40 |
| Sensitivity adjustment: | 20-turn potentiometer |
| Polarity: | PNP |
| Output: | Light-on + Dark-on |
| Interface: | Standard output |
| Connection: | PVC, 3 m, 4 wire |
| Supply voltage: | 10...36 VDC |
| Switching frequency max. [Hz]: | 1000 |
| Housing material: | PBTP (Crastin) |
| Temperature range: | -25...55 °C |
| Enclosure rating (IP): | IP 67 |
Logistic parameters
| ECCN: | |
| Country of Origin: | |
| EAN: | |
| Weight: | 0.00 kg |
| Length: | 0.00 m |
| Width: | 0.00 m |
| Height: | 0.00 m |
