DW-AS-62B-C44
320-820-405
Operating distance Sn: | 20 mm |
Housing size [mm]: | 40 x 40 (C44) |
Mounting: | Embeddable |
Polarity: | NPN |
Output: | Changeover (NO/NC) |
Interface: | Standard output |
Connection: | M12 4-pin |
Supply voltage: | 10…30 VDC |
Switching frequency max. [Hz]: | 100 |
Housing material: | PA GF |
Enclosure rating (IP): | IP 68 / IP 69K |
ECCN: | |
Country of Origin: | |
EAN: | |
Weight: | 0.00 kg |
Length: | 0.00 m |
Width: | 0.00 m |
Height: | 0.00 m |
