Article image EPINUS4KG/6M

Comitronic-BTI EPINUS4KG/6M

Position control for doors / casings on dangerous machinery with magnetic holding devices

On Request. Please send us an email to inquire the price and avaliability.
"ucnguBrctvdgcxgt0eqo"

Description

Technical parameters

40N integrated stainless steel magnetic door holding Contactless coded electronic sensor Total safety management with an AWAX controller Level of performance with AWAX controller: up to PL = e Safety category up to 4 with an AWAX controller Time before dangerous failure MTTFd = 360 years Max. activation distance 3 mm, 2 mm hysteresis Holding Force transmitter + receiver in contact = 40N Safety contacts/diagnostics 2 x NO 0.8A max / 48V redundant and 1 x PNP 250mA Detection encoding mono-code inviolable Reset automatic Attachment 4 tamper-proof 5mm Mounting position 1 Material INOX 316L mirror polished Electrical Connection 3, 6, 12m cable or 50cm cord PVC M12 (ref. + MKT) Water resistance IP 68  Temperature -25°C to +70°C. Marking laser engraving with mechanical punching of the serial number for permanent traceability

Logistic parameters

ECCN:
Country of Origin:
EAN:
Weight: 0.00 kg
Length: 0.00 m
Width: 0.00 m
Height: 0.00 m
