Comitronic-BTI
CB01
Request a Quote
Image copyright: Comitronic-BTI
Comitronic-BTI CB01
CB01 per 10 pieces (Without screen printing and without programming), square RFID key ring
On Request. Please send us an email to inquire the price and avaliability.
"ucnguBrctvdgcxgt0eqo"
Description
Hierarchical RFID 8 access control zones, 250 badges. 22.5mm DIN rail enclosure with removable terminals. No software or PC configuration. 8 combinable outputs
Technical parameters
| Life cycle: | 20 years Max activation distance up to 45 mm Contact 8 x 200 mA PNP for 8-bit format Detection encoding 16 million Indicator 8 LEDs indicating the pathways activated Action Momentary (ref + M), bistable (ref + B), timed (ref + MKT) Mounting symmetrical DIN 35mm rail after DIN 50022 Mounting IP 54 electrical enclosure Material PA6 Electrical connection Maximum 14 AWG (2.08 mm²) Sealing IP 67 Temperature -15 °C to +60 °C Marking label + serial number for traceability Option badge nail, screw, plate screw, key chain, card ... etc. |
Logistic parameters
| ECCN: | |
| Country of Origin: | |
| EAN: | |
| Weight: | 0.00 kg |
| Length: | 0.00 m |
| Width: | 0.00 m |
| Height: | 0.00 m |
