Article image 2CDG120065R0011

ABB 2CDG120065R0011

BCM/S16.1.3.1

BCM/S16.1.3.1 BAC Module, 8 Digital Inputs/Outputs, 24 V, Relay

On Request. Please send us an email to inquire the price and avaliability.
"ucnguBrctvdgcxgt0eqo"

Description

Extension module for the BAC/S Building Automation Controller KNX with 8 digital inputs and 8 digital outputs. The digital inputs process 24 V DC signals. The relay outputs switch a maximum of 2 A at 24 V DC and a maximum of 1.5 A at 120/240 V AC. Connection of the cables via pluggable spring terminals.

Logistic parameters

ECCN:
Country of Origin: CN
EAN:
Weight: 0.21 kg
Length: 0.074 m
Width: 0.034 m
Height: 0.135 m
