Article image 1SVR427030R0000

ABB 1SVR427030R0000

CP-E 24/0.75

CP-E 24/0.75 Power supply In:100-240VAC Out: 24VDC/0.75A

On Request. Please send us an email to inquire the price and avaliability.
"ucnguBrctvdgcxgt0eqo"

Description

The CP-E 24/0.75 is a power supply from the CP-E range. The primary switch mode power supply offers a wide range input of 90-264 V AC and 120-375 V DC, rated input voltage is 100-240 V AC. The rated output power is 18 W, rated output current is 0.75 A at an output voltage of 24 V DC. The output voltage is adjustable within a range of 21.6 to 28.8 V DC. The output characteristic is hiccup-mode. The power supply allows parallel operation to enable redundancy. A redundancy unit is available as accessory.

Logistic parameters

ECCN:
Country of Origin: TW
EAN:
Weight: 0.14 kg
Length: 0.114 m
Width: 0.0225 m
Height: 0.09 m
