1SBV012230R1202
LS33P30B02
LS33P30B02 Limit Switch
LS33P30B02 is a 30 mm wide, standard Limit Switch made of fiber-glass reinforced UL-V0 material, with 2 mounting holes at the top, 1 ISO M20x1.5 cable entry on the bottom, plastic roller lever (Ø12,5 mm) on plastic plunger actuator for horizontal movement and 2 N.C snap action (Zb type) contacts
ECCN: | |
Country of Origin: | FR |
EAN: | 3471522648181 |
Weight: | 0.06 kg |
Length: | 0.032 m |
Width: | 0.03 m |
Height: | 0.095 m |
