Product
Weidmueller
9427370000
MULTIMETER C 2606
Request a Quote
Image copyright: Weidmueller
Weidmueller 9427370000
MULTIMETER C 2606
On Request. Please send us an email to inquire the price and avaliability.
"ucnguBrctvdgcxgt0eqo"
Description
Technical parameters
| Type: | MULTIMETER C 2606 |
| Order No.: | 9427370000 |
| Version: | Digital clamp-on measuring device |
| GTIN (EAN): | 4032248407019 |
| Qty.: | 1 pc(s). |
| Width: | 281 mm |
| Width (inches): | 11.063 inch |
| Height: | 53 mm |
| Height (inches): | 2.087 inch |
| Depth: | 108 mm |
| Depth (inches): | 4.252 inch |
| Weight: | 570 g |
| Net weight: | 888.2 g |
| REACH SVHC: | Lead 7439-92-1 |
| AC voltage measuring range: | 0.66 - 750 V |
| Battery type: | 9V block battery |
| DC voltage measuring range: | 0.66 - 1000 V |
| Display: | digital |
| Frequency measurement: | Yes |
| Frequency range, max.: | 66 Hz |
| Frequency range, min.: | 1 MHz |
| Measured capacitance value, max.: | 6.6 mF |
| Measured capacitance value, min.: | 6.6 nF |
| Measured current value, max.: | 2,000 A |
| Measuring range category: | CAT III |
| Opening width of current-measuring clamp-on attachment: | 57 mm |
| Resistance measuring range, max.: | 66 MΩ |
| Resistance measuring range, min.: | 660 Ω |
| Resolution of AC voltage: | ± 0.5% |
| Resolution of DC voltage: | ± 0.5% |
| Selection of measuring range: | Manual |
| Tested and approved according to: | VDE 0680, Part 5 |
| Type of current: | AC, DC |
| Working temperature, max.: | 50 °C |
| Working temperature, min.: | 0 °C |
| Product information: | Min/max function only applies for the DC range. |
| ETIM 6.0: | EC000380 |
| ETIM 7.0: | EC000380 |
| eClass 9.0: | 27-20-03-12 |
| eClass 9.1: | 27-20-03-12 |
| eClass 10.0: | 27-20-03-12 |
| UNSPSC: | 41-11-36-37 |
| ROHS: | Conform |
| Type: | MULTIMETER C 2606 |
| Order No.: | 9427370000 |
| Version: | Digital clamp-on measuring device |
| GTIN (EAN): | 4032248407019 |
| Qty.: | 1 pc(s). |
| Width: | 281 mm |
| Width (inches): | 11.063 inch |
| Height: | 53 mm |
| Height (inches): | 2.087 inch |
| Depth: | 108 mm |
| Depth (inches): | 4.252 inch |
| Weight: | 570 g |
| Net weight: | 888.2 g |
| REACH SVHC: | Lead 7439-92-1 |
| AC voltage measuring range: | 0.66 - 750 V |
| Battery type: | 9V block battery |
| DC voltage measuring range: | 0.66 - 1000 V |
| Display: | digital |
| Frequency measurement: | Yes |
| Frequency range, max.: | 66 Hz |
| Frequency range, min.: | 1 MHz |
| Measured capacitance value, max.: | 6.6 mF |
| Measured capacitance value, min.: | 6.6 nF |
| Measured current value, max.: | 2,000 A |
| Measuring range category: | CAT III |
| Opening width of current-measuring clamp-on attachment: | 57 mm |
| Resistance measuring range, max.: | 66 MΩ |
| Resistance measuring range, min.: | 660 Ω |
| Resolution of AC voltage: | ± 0.5% |
| Resolution of DC voltage: | ± 0.5% |
| Selection of measuring range: | Manual |
| Tested and approved according to: | VDE 0680, Part 5 |
| Type of current: | AC, DC |
| Working temperature, max.: | 50 °C |
| Working temperature, min.: | 0 °C |
| Product information: | Min/max function only applies for the DC range. |
| ETIM 6.0: | EC000380 |
| ETIM 7.0: | EC000380 |
| eClass 9.0: | 27-20-03-12 |
| eClass 9.1: | 27-20-03-12 |
| eClass 10.0: | 27-20-03-12 |
| UNSPSC: | 41-11-36-37 |
| ROHS: | Conform |
Logistic parameters
| ECCN: | |
| Country of Origin: | |
| EAN: | |
| Weight: | 0.979 kg |
| Length: | 0.00 m |
| Width: | 0.00 m |
| Height: | 0.00 m |
