Product
Weidmueller
2457850000
U-LINK-LIC-STD-500-1Y
Request a Quote
Image copyright: Weidmueller
Weidmueller 2457850000
U-LINK-LIC-STD-500-1Y
On Request. Please send us an email to inquire the price and avaliability.
"ucnguBrctvdgcxgt0eqo"
Description
Technical parameters
| Type: | U-LINK-LIC-STD-500-1Y |
| Order No.: | 2457850000 |
| Version: | “Standard 500” version software licence for u-link Remote Access Service. Can be used to upgrade an entry version or "Standard 150/300" versions or to extend period of a “Standard 300” version |
| GTIN (EAN): | 4050118472851 |
| Qty.: | 1 pc(s). |
| Net weight: | 73 g |
| China-VPN: | Reliable VPN connection to and from China |
| Device management: | Illustration of the device infrastructure (remote access objects) in a clearly defined tree structure via location, group and device objects |
| Firmware management: | Display of the firmware version of all routers and the possibility of timed, automated firmware updates |
| Monthly data volume and bandwidth: | <= 5 GB with max. 1 Mbit/s, > 5 GB with max. 500 Kbit/s. Increase by 1 GB/month with 1 Mbit/s per added-on pass-through VPN connection, for data volume > 12 GB/month max. 500 Kbit/s |
| Number of configurable router objects (access points remote network): | 500, additional license models available on request |
| Number of configurable user objects (service PC): | Unrestricted |
| Password guideline: | Increased security through configurable specification of minimum requirements for the password quality and validity period |
| Period: | 1 year from activation of the licence key. When extending a “Standard 500” version, the validity period is extended by 1 year from the expiry date of the current period, but not less than 1 year., Note: Where the validity period has expired, the bandwidth is automatically reduced to the values used with the free entry version (<= 1 GB with max. 500 kbit/s, > 1 GB with max. 64 kbit/s) |
| Simultaneously usable pass-through VPN connections: | 3 (can be extended by adding on other pass-through VPN connections) |
| System availability: | ≥ 99.6% |
| Usage information: | Extended reporting and statistical information (itemised statement, usage duration, data volume) |
| User organisation: | Organisation of service users in groups, assignment of selective access rights to device topology, group-dependent assignment of rights re. device configuration and user administration |
| Hardware (service PC): | PC with operating system Windows 7, 8 or 10 |
| Hardware, remote target network: | Weidmüller router (except IE-SR-2GT-LAN-FN; 1489940000), u-link VPN access integrated in firmware (from V3.0.1) |
| Portal administration (user/device configuration): | Standard browser (IE, Edge, Chrome, Firefox) via an HTTPS connection (SSL), login via username and password |
| VPN software (service PC): | u-link VPN-client (installation on PC) |
| Activation: | Client account administrator enters the licence key in the u-link portal (functions immediately available) |
| Included in delivery: | Letter with licence key |
| ETIM 6.0: | EC000809 |
| ETIM 7.0: | EC000809 |
| eClass 9.0: | 27-24-25-01 |
| eClass 9.1: | 27-24-25-01 |
| eClass 10.0: | 27-24-25-01 |
| Type: | U-LINK-LIC-STD-500-1Y |
| Order No.: | 2457850000 |
| Version: | “Standard 500” version software licence for u-link Remote Access Service. Can be used to upgrade an entry version or "Standard 150/300" versions or to extend period of a “Standard 300” version |
| GTIN (EAN): | 4050118472851 |
| Qty.: | 1 pc(s). |
| Net weight: | 73 g |
| China-VPN: | Reliable VPN connection to and from China |
| Device management: | Illustration of the device infrastructure (remote access objects) in a clearly defined tree structure via location, group and device objects |
| Firmware management: | Display of the firmware version of all routers and the possibility of timed, automated firmware updates |
| Monthly data volume and bandwidth: | <= 5 GB with max. 1 Mbit/s, > 5 GB with max. 500 Kbit/s. Increase by 1 GB/month with 1 Mbit/s per added-on pass-through VPN connection, for data volume > 12 GB/month max. 500 Kbit/s |
| Number of configurable router objects (access points remote network): | 500, additional license models available on request |
| Number of configurable user objects (service PC): | Unrestricted |
| Password guideline: | Increased security through configurable specification of minimum requirements for the password quality and validity period |
| Period: | 1 year from activation of the licence key. When extending a “Standard 500” version, the validity period is extended by 1 year from the expiry date of the current period, but not less than 1 year., Note: Where the validity period has expired, the bandwidth is automatically reduced to the values used with the free entry version (<= 1 GB with max. 500 kbit/s, > 1 GB with max. 64 kbit/s) |
| Simultaneously usable pass-through VPN connections: | 3 (can be extended by adding on other pass-through VPN connections) |
| System availability: | ≥ 99.6% |
| Usage information: | Extended reporting and statistical information (itemised statement, usage duration, data volume) |
| User organisation: | Organisation of service users in groups, assignment of selective access rights to device topology, group-dependent assignment of rights re. device configuration and user administration |
| Hardware (service PC): | PC with operating system Windows 7, 8 or 10 |
| Hardware, remote target network: | Weidmüller router (except IE-SR-2GT-LAN-FN; 1489940000), u-link VPN access integrated in firmware (from V3.0.1) |
| Portal administration (user/device configuration): | Standard browser (IE, Edge, Chrome, Firefox) via an HTTPS connection (SSL), login via username and password |
| VPN software (service PC): | u-link VPN-client (installation on PC) |
| Activation: | Client account administrator enters the licence key in the u-link portal (functions immediately available) |
| Included in delivery: | Letter with licence key |
| ETIM 6.0: | EC000809 |
| ETIM 7.0: | EC000809 |
| eClass 9.0: | 27-24-25-01 |
| eClass 9.1: | 27-24-25-01 |
| eClass 10.0: | 27-24-25-01 |
Logistic parameters
| ECCN: | |
| Country of Origin: | |
| EAN: | |
| Weight: | 0.084 kg |
| Length: | 0.00 m |
| Width: | 0.00 m |
| Height: | 0.00 m |
