Pilz 630382
PSEN op4S-1-2
Safety light curtain, type 4, PL e, laser sensor increased range.
On Request. Please send us an email to inquire the price and avaliability.
"ucnguBrctvdgcxgt0eqo"
Description
Technical parameters
| Certifications:: | CE, cULus Listed, EAC (Eurasian), TÜV |
| Sensor principle:: | Laser |
| Type in accordance with EC 61496:: | 4 |
| Operating range (m):: | 0,0 - 40,0 |
| Reaction time:: | 0.33 ms |
| Number of OSSD outputs:: | 0 |
| Muting:: | No |
| Supply voltage (V):: | 20,0 - 30,0 |
| Supply voltage type:: | DC |
| Metric diameter:: | M18 |
| Protection type, housing:: | IP67 |
| Application in accordance with:: | EN 61496-1, EN 61496-2 |
| Resolution, protection type:: | Body |
| Depth dimension:: | 68.2 mm |
| Gross weight:: | 75 g |
| Net weight:: | 47 g |
| Ambient temperature:: | -10 - 50 °C |
Logistic parameters
| ECCN: | |
| Country of Origin: | |
| EAN: | |
| Weight: | 0.00 kg |
| Length: | 0.00 m |
| Width: | 0.00 m |
| Height: | 0.00 m |
