Image copyright: Leuze electronic
Leuze electronic 50129661
BCL 900i SN 102
BCL 900i SN 102 - Stationary bar code reader
On Request. Please send us an email to inquire the price and avaliability.
"ucnguBrctvdgcxgt0eqo"
Description
Technical parameters
| Series: | BCL 900i |
| Functions: | Code fragment technology, Alignment mode, AutoConfig, LED indicator |
| Code types, readable: | Code 128, 2/5 Interleaved, Codabar, Code 39, Code 93, EAN 128, EAN 8/13, EAN Addendum, UPC |
| Scanning rate, typical: | 1,000 scans/s |
| Reading distance: | 525 ... 1,500 mm |
| Light source: | Laser, Red |
| Laser light wavelength: | 650 nm |
| Laser class: | 2, IEC/EN 60825-1:2007 |
| Modulus size: | 0.25 ... 0.38 mm |
| Reading method: | Line scanner |
| Scanning rate: | 1,000 scans/s |
| Beam deflection: | Via rotating polygon wheel |
| Light beam exit: | Front |
| Supply voltage UB: | 10 ... 30 V, DC |
| Power consumption, max.: | 10 W |
| Number of digital switching inputs: | 3 Piece(s) |
| Number of digital switching outputs: | 2 Piece(s) |
| Type: | Ethernet, RS 232, RS 422 |
| Function: | Process |
| Function: | Process |
| Switch functionality: | Integrated |
| Transmission protocol: | TCP/IP , UDP |
| Number of connections: | 4 Piece(s) |
| Function: | Voltage supply |
| Type of connection: | Connector |
| Designation on device: | POWER |
| Thread size: | M12 |
| Type: | Male |
| Material: | Metal |
| No. of pins: | 4 -pin |
| Encoding: | A-coded |
| Function: | Internal communication interface |
| Type of connection: | Connector |
| Designation on device: | I/O |
| Thread size: | M12 |
| Type: | Male |
| Material: | Metal |
| No. of pins: | 17 -pin |
| Encoding: | A-coded |
| Function: | Data interface |
| Type of connection: | Connector |
| Designation on device: | ETH1 |
| Thread size: | M12 |
| Type: | Female |
| Material: | Metal |
| No. of pins: | 4 -pin |
| Encoding: | D-coded |
| Function: | Data interface |
| Type of connection: | Connector |
| Designation on device: | ETH2 |
| Thread size: | M12 |
| Type: | Female |
| Material: | Metal |
| No. of pins: | 4 -pin |
| Encoding: | D-coded |
| Design: | Cubic |
| Dimension (W x H x L): | 216 mm x 96 mm x 127 mm |
| Housing material: | Metal, Diecast aluminum |
| Lens cover material: | Glass |
| Net weight: | 2,000 g |
| Housing color: | Red, Silver |
| Type of fastening: | Via optional mounting device |
| Type of display: | LED |
| Number of LEDs: | 5 Piece(s) |
| Type of configuration: | Via web browser |
| Operational controls: | Button(s) |
| Ambient temperature, operation: | 0 ... 50 °C |
| Ambient temperature, storage: | -20 ... 70 °C |
| Relative humidity (non-condensing): | 0 ... 90 % |
| Degree of protection: | IP 65 |
| Certifications: | c CSA US |
| Test procedure for EMC in accordance with standard: | EN 61000-4-2, -3, -4, -6, EN 55022 |
| Test procedure for shock in accordance with standard: | IEC 60068-2-27, test Ea |
| Test procedure for continuous shock in accordance with standard: | IEC 60068-2-29, test Eb |
| Test procedure for vibration in accordance with standard: | IEC 60068-2-6, test Fc |
| Customs tariff number: | 84719000 |
| eCl@ss 8.0: | 27280102 |
| eCl@ss 9.0: | 27280102 |
| ETIM 5.0: | EC002550 |
| ETIM 6.0: | EC002550 |
Logistic parameters
| ECCN: | |
| Country of Origin: | Italien |
| EAN: | |
| Weight: | 4.43 kg |
| Length: | 0.00 m |
| Width: | 0.00 m |
| Height: | 0.00 m |
