Product
IPF
PK170020
Request a Quote
Image copyright: IPF
IPF PK170020
On Request. Please send us an email to inquire the price and avaliability.
"ucnguBrctvdgcxgt0eqo"
Description
Technical parameters
| Housing material: | Zinc die-cast |
| Sensor width: | 15.4mm |
| Sensor length: | 50mm |
| Ambient temperature: | -10 - 50°C |
| Sensor height: | 50mm |
| Voltage type: | DC |
| Type of electrical connection: | Connector M12 |
| Rated switching current: | 200mA |
| Sensing range: | 0 - 250mm |
| Voltage drop: | 2V |
| Light color, selectable: | no |
| Number of pins: | 4 |
| Operating voltage: | 12 - 30V |
| Short-circuit protection: | yes |
| Reverse polarity protection: | yes |
| Programmable via software: | no |
| Analogue output 0 V ... 5,5 V: | no |
| Wavelength of the sensor: | 650nm |
| Detection of fluorescent materials: | no |
| Transmitted light applications: | no |
| Detection of print marks: | no |
| Turbidity inspection: | no |
| eClass 7.0: | 27270906 |
| eClass 7.1: | 27270906 |
| eClass 8.0: | 27270906 |
| eClass 9.0: | 27270906 |
| eClass 9.1: | 27270906 |
| ETIM-6.0: | EC001820 |
| ETIM-7.0: | EC001820 |
| IPF Product Group: | 168 |
| shipping weight: | 0.12kg |
| packaging dimensions: | 77.0mm x 25.0mm x 123.0mm |
| customs tariff number: | 85365019 |
Logistic parameters
| ECCN: | |
| Country of Origin: | |
| EAN: | |
| Weight: | 0.00 kg |
| Length: | 0.00 m |
| Width: | 0.00 m |
| Height: | 0.00 m |
