Product
Di-soric
209610
AL 24-50-1150-1240 Q-R
Request a Quote
Image copyright: Di-soric
Di-soric 209610
AL 24-50-1150-1240 Q-R
Display strip
On Request. Please send us an email to inquire the price and avaliability.
"ucnguBrctvdgcxgt0eqo"
Description
To be used with evaluation electronics LVx-ALM ... Parameterization by software. Compact design. Aluminium casing. Easy-to-install
Downloads
Technical parameters
| Operation with: | Evaluation electronics LVX-ALM ... |
| Size: | 10 x 27 mm (Profile cross section) |
| Number: | 24 LEDs |
| Distance of the indicator LED: | 50 mm |
| Dimension A: | 120 mm |
| Dimension B: | 500 mm |
| Display range H: | 1150 mm |
| Profile length: | 1240 mm |
| Light colour: | Red |
| Shock-/vibration load: | 10 ... 55 Hz / 1,0 mm / 30 g |
| Ambient temperature, operation: | -25 … +40 °C |
| Protection class: | IP 54 |
| Casing material: | Aluminium anodized |
| Material: | plastic (Window) |
| Connection: | Cable, 4,0 m, with connector |
Logistic parameters
| ECCN: | |
| Country of Origin: | |
| EAN: | |
| Weight: | 0.12 kg |
| Length: | 0.00 m |
| Width: | 0.00 m |
| Height: | 0.00 m |
