Product
ABB
2CPX035741R9999
KA213
Request a Quote
Image copyright: ABB
ABB 2CPX035741R9999
KA213
KA213 Meter Board Compl. 7R
On Request. Please send us an email to inquire the price and avaliability.
"ucnguBrctvdgcxgt0eqo"
Description
Meter panel, suitable for series: ComfortLine A and ComfortLine AD, fully assembled module, with Metering cross, rated current 63 A, dimensions in mm (H x W x D): 1050 x 250 x 160, Metering module pre-wired, Earthing system TN-S, 5-pole, net side compartment, meter space: with busbar, net side compartment, SG space: with busbar, Number of SG spaces 1, Ratchet unit 7 GU, Overall height 3, panel width 1, Space units 84, covers out of Plastic, 90 degree press and turn closure, RAL 7035
Logistic parameters
| ECCN: | |
| Country of Origin: | DE |
| EAN: | 4011617357414 |
| Weight: | 5.05 kg |
| Length: | 1.06 m |
| Width: | 0.25 m |
| Height: | 0.14 m |
