Beckhoff KL9195
KL9195 | Shield terminal
Bajo pedido. Envíenos un correo electrónico para consultar el precio y la disponibilidad.
"ucnguBrctvdgcxgt0eqo"
Descripción
The KL9195 Bus Terminal allows the supply voltage to be accessed a number of times via spring force terminals. It makes it unnecessary to use additional terminal blocks on the terminal strip. The KL9195 can be used for the connection of screens. The KL9195 connects the spring force contacts directly to the DIN rail, and can optimally ground incoming electromagnetic radiation. The two power contacts are looped through by the KL9195, allowing two wires to be connected to each power contact.
Parámetros técnicos
| Nominal voltage: | arbitrary up to 230 V AC |
| Current load: | ≤ 10 A |
| Integrated fine-wire fuse: | – |
| Diagnostics: | – |
| Power LED: | – |
| Defect LED: | – |
| Reported to K-bus: | – |
| PE contact: | – |
| Shield connection: | 2 x |
| Renewed infeed: | – |
| Connection facility to additional power contact: | 2 |
| K-bus, looped through: | yes |
| Bit width in the process image: | 0 |
| Electrical connection to DIN rail: | yes |
| Current consumption K-bus: | – |
| Electrical isolation: | – |
| Housing width: | 12 mm |
| Weight: | approx. 50 g |
| Side by side mounting on Bus Terminals with power contact: | only 2 power contacts |
| Side by side mounting on Bus Terminals without power contact: | – |
| Operating/storage temperature: | 0…+55 °C/-25…+85 °C |
| Pluggable wiring: | for all KSxxxx Bus Terminals |
| Approvals/markings: | CE, UL, ATEX, GL |
| Ex marking: | II 3 G Ex nA IIC T4 Gc |
