Derechos autor imagen: Beckhoff
Beckhoff EL2032
EL2032 | 2-channel digital output terminal 24 V DC, 2 A
Bajo pedido. Envíenos un correo electrónico para consultar el precio y la disponibilidad.
"ucnguBrctvdgcxgt0eqo"
Descripción
The EL2032 digital output terminal connects the binary control signals from the automation unit on to the actuators at the process level with electrical isolation. The EtherCAT Terminal offers short-circuit protection of the outputs and contains two channels that indicate their signal state by means of light emitting diodes.
Parámetros técnicos
| Connection technology: | 4-wire |
| Number of outputs: | 2 |
| Rated load voltage: | 24 V DC (-15 %/+20 %) |
| Load type: | ohmic, inductive, lamp load |
| Distributed clocks: | – |
| Max. output current: | 2.0 A (short-circuit-proof) per channel |
| Short circuit current: | typ. < 70 A |
| Reverse voltage protection: | yes |
| Breaking energy: | < 1.7 J/channel |
| Switching times: | typ. TON: 40 µs, typ. TOFF: 200 µs |
| Current consumption E-bus: | typ. 100 mA |
| Electrical isolation: | 500 V (E-bus/field potential) |
| Current consumption power contacts: | typ. 13 mA + load |
| Bit width in the process image: | 2 outputs, 2 inputs (diagnostics) |
| Configuration: | no address or configuration setting |
| Weight: | approx. 55 g |
| Operating/storage temperature: | -25…+60 °C/-40…+85 °C |
| Relative humidity: | 95 %, no condensation |
| Vibration/shock resistance: | conforms to EN 60068-2-6/EN 60068-2-27 |
| EMC immunity/emission: | conforms to EN 61000-6-2/EN 61000-6-4 |
| Protect. class/installation pos.: | IP 20/variable |
| Pluggable wiring: | for all ESxxxx terminals |
| Approvals: | CE, UL, Ex |
