Wago 787-1668/000-054

ECB 8-CH DC 24V

Beschreibung

Space-saving ECB with eight channels. Nominal current: 2 … 10 A (adjustable for each channel via sealable selector switch); Factory preset: 2 A (when switched off). Switch-on capacity > 50000 μF per channel. One illuminated, three-colored button per channel simplifies switching (on/off), resetting, and on-site diagnostics. Time-delayed switching of channels. Tripped message (group signal). Remote input resets all tripped channels. Potential-free signal contact 13 / 14 reports “channel switched off” and “tripped channel” – does not support communication via pulse sequence.
