Leuze electronic
50103709
HRTL 8/66-350,5000
Сделать запрос
Авторское право на изображение: Leuze electronic
Leuze electronic 50103709
HRTL 8/66-350,5000
HRTL 8/66-350,5000 - Diffuse sensor with background suppression
По запросу. Пожалуйста, отправьте нам письмо, чтобы узнать цену и наличие.
"ucnguBrctvdgcxgt0eqo"
Описание
Технические характеристики
| Series: | 8 |
| Operating principle: | Diffuse reflection principle with background suppression |
| Operating range, white 90%: | 0.007 ... 0.35 m |
| Operating range, gray 18%: | 0.01 ... 0.33 m |
| Operating range, black 6%: | 0.012 ... 0.3 m |
| Operating range limit, white 90%: | 0.007 ... 0.4 m |
| Operating range limit, gray 18%: | 0.01 ... 0.37 m |
| Operating range limit, black 6%: | 0.012 ... 0.34 m |
| Light source: | Laser, Red |
| Laser class: | 2, IEC/EN 60825-1:2007 |
| Protective circuit: | Polarity reversal protection, Short circuit protected |
| Supply voltage UB: | 10 ... 30 V, DC |
| Residual ripple: | 0 ... 15 %, From UB |
| Open-circuit current: | 0 ... 35 mA |
| Number of digital switching outputs: | 2 Piece(s) |
| Switching element: | Transistor, Push-pull |
| Switching principle: | Light switching (PNP)/dark switching (NPN) |
| Switching element: | Transistor, Push-pull |
| Switching principle: | Dark switching (PNP)/light switching (NPN) |
| Switching frequency: | 2,000 Hz |
| Response time: | 0.25 ms |
| Function: | Voltage supply, Signal OUT |
| Type of connection: | Cable |
| Cable length: | 5,000 mm |
| Number of conductors: | 5 -wire |
| Dimension (W x H x L): | 15 mm x 48 mm x 38 mm |
| Housing material: | Metal, Zinc |
| Lens cover material: | Glass |
| Net weight: | 200 g |
| Type of fastening: | Through-hole mounting, Dovetail grooves, Mounting thread, Via optional mounting device |
| Compatibility of materials: | ECOLAB |
| Operational controls: | Multiturn potentiometer |
| Ambient temperature, operation: | -10 ... 40 °C |
| Degree of protection: | IP 67, IP 69K |
| Protection class: | II |
| Certifications: | c UL US |
| Standards applied: | IEC 60947-5-2 |
| Customs tariff number: | 85365019 |
| eCl@ss 8.0: | 27270904 |
| eCl@ss 9.0: | 27270904 |
| ETIM 5.0: | EC002719 |
| ETIM 6.0: | EC002719 |
Логистические характеристики
| ТН ВЭД: | |
| Страна происхождения: | Deutschland |
| EAN: | |
| Вес: | 0,27 kg |
| Длина: | 0,00 m |
| Ширина: | 0,00 m |
| Высота: | 0,00 m |
