Escha 8048829
IE-RJ45SS8.002-2-IE-RJ45SS8.002/S3500
RJ45 male, straight, RJ45 male, straight, Industrial Ethernet, 10 GBit/s, 8 poles, shielded
По запросу. Пожалуйста, отправьте нам письмо, чтобы узнать цену и наличие.
"ucnguBrctvdgcxgt0eqo"
Описание
Shielded PUR-cable for industrial applications. The cable meets the UL-Style 20963 and the Cat7 (electrical properties according to EN50288-4-2) requirements. Materials and a constructive setup allow for increased mechanical stresses (abrasion, bending, vibrations etc.) of the cable.
Загрузки
Технические характеристики
| Outer diameter of jacket: | 6,40 mm |
| Number of pins: | 8 |
| Jacket color: | GN, similar RAL6018 |
| Allocation: | T568B |
| Wire insulation material: | PE |
| Wire colors: | WH/OG ; WH/GN ; WH/BN ; WH/BU |
| Insulation resistance (Ω): | ≥10 8 |
| Transmission features: | Cat6A |
| Temperature range (fixed): | -40°C...+80°C |
| Temperature range (repeated): | -20°C...+60°C |
| Halogen-free: | Yes |
| Grip body material: | Plastic, TPE, BK |
| Material of shielding housing: | Metal, CuZn, nickel-plated |
| Shielding: | Yes |
| Special features: | seawater resistant, recyclable, LABS free, RoHs compliant, acid- and alkali resistant, UV resistant, hydrolysis proof, halogen free, oil resistant, high flexibility, no corrosive gases, microbes resistant, no fire propargation |
| Degree of protection (mounted): | >750 mating cycles |
| Mechanical life-cycle: | 1 |
| Degree of pollution: | with shielding |
Логистические характеристики
| ТН ВЭД: | |
| Страна происхождения: | Deutschland |
| EAN: | |
| Вес: | 0,11 kg |
| Длина: | 0,00 m |
| Ширина: | 0,00 m |
| Высота: | 0,00 m |
