Produkt
Weidmueller
8773600000
MI8DO-S F10 S
Poproś o ofertę
Prawa autorskie do obrazu: Weidmueller
Weidmueller 8773600000
MI8DO-S F10 S
1463520000
Na prośbę. Prześlij nam wiadomość e-mail z zapytaniem o cenę i dostępność.
"ucnguBrctvdgcxgt0eqo"
Opis
Parametry techniczne
| Delivery status: | Discontinued |
| Available until: | 2016-09-30 |
| Type: | MI8DO-S F10 S |
| Order No.: | 8773600000 |
| Version: | Plug-in connector in acc. with IEC60603-13 / DIN41651, Screw connection |
| GTIN (EAN): | 4032248442133 |
| Qty.: | 1 pc(s). |
| Length: | 48 mm |
| Length (inches): | 1.89 inch |
| Width: | 59 mm |
| Width (inches): | 2.323 inch |
| Height: | 53 mm |
| Height (inches): | 2.087 inch |
| Net weight: | 78 g |
| Operating temperature, max.: | 55 °C |
| Operating temperature, min.: | 0 °C |
| Storage temperature, max.: | 85 °C |
| Storage temperature, min.: | -20 °C |
| Operating temperature: | 0...55 °C |
| Ambient temperature: | 0 °C...+55 °C |
| Storage temperature: | -20...85 °C |
| Connection on control side: | Plug-in connector in acc. with IEC60603-13 / DIN41651 |
| Number of poles (control side): | 10-pole plug |
| Voltage supply: | 24 V DC |
| Supply plug-in connectors: | TOP 1.5GS2/180 |
| Operating voltage: | 24 V DC |
| Max. current per channel: | 0.5 A |
| Total operating current: | 2 A |
| According to: | DIN EN 50178 |
| Rated insulation voltage: | < 50 V AC |
| Surge voltage category: | III |
| Pollution severity level: | 2 |
| Insulation test voltage: | 0.35 kVAC |
| Type of connection: | Screw connection |
| Clamping range, min.: | 2.5 mm² |
| Clamping range, max.: | 0.13 mm² |
| Solid, min. H05(07) V-U: | 2.5 mm² |
| Solid, max. H05(07) V-U: | 0.5 mm² |
| Flexible, min. H05(07) V-K: | 2.5 mm² |
| Flexible, max. H05(07) V-K: | 0.5 mm² |
| Flexible with sleeve, max.: | 0.5 mm² |
| Flexible with sleeve, min.: | 2.5 mm² |
| Ferrule with plastic collar, max.: | 0.5 mm² |
| Wire cross-section, min. AWG: | AWG 14 |
| Wire cross-section, max. AWG: | AWG 26 |
| Tightening torque, min.: | 0.4 Nm |
| Tightening torque, max.: | 0.5 Nm |
| Stripping length: | 10 mm |
| ETIM 6.0: | EC002584 |
| ETIM 7.0: | EC002584 |
| eClass 9.0: | 27-33-02-92 |
| eClass 9.1: | 27-24-22-92 |
| eClass 10.0: | 27-33-02-92 |
| UNSPSC: | 30-21-18-01 |
| ROHS: | Conform |
| Delivery status: | Discontinued |
| Available until: | 2016-09-30 |
| Type: | MI8DO-S F10 S |
| Order No.: | 8773600000 |
| Version: | Plug-in connector in acc. with IEC60603-13 / DIN41651, Screw connection |
| GTIN (EAN): | 4032248442133 |
| Qty.: | 1 pc(s). |
| Length: | 48 mm |
| Length (inches): | 1.89 inch |
| Width: | 59 mm |
| Width (inches): | 2.323 inch |
| Height: | 53 mm |
| Height (inches): | 2.087 inch |
| Net weight: | 78 g |
| Operating temperature, max.: | 55 °C |
| Operating temperature, min.: | 0 °C |
| Storage temperature, max.: | 85 °C |
| Storage temperature, min.: | -20 °C |
| Operating temperature: | 0...55 °C |
| Ambient temperature: | 0 °C...+55 °C |
| Storage temperature: | -20...85 °C |
| Connection on control side: | Plug-in connector in acc. with IEC60603-13 / DIN41651 |
| Number of poles (control side): | 10-pole plug |
| Voltage supply: | 24 V DC |
| Supply plug-in connectors: | TOP 1.5GS2/180 |
| Operating voltage: | 24 V DC |
| Max. current per channel: | 0.5 A |
| Total operating current: | 2 A |
| According to: | DIN EN 50178 |
| Rated insulation voltage: | < 50 V AC |
| Surge voltage category: | III |
| Pollution severity level: | 2 |
| Insulation test voltage: | 0.35 kVAC |
| Type of connection: | Screw connection |
| Clamping range, min.: | 2.5 mm² |
| Clamping range, max.: | 0.13 mm² |
| Solid, min. H05(07) V-U: | 2.5 mm² |
| Solid, max. H05(07) V-U: | 0.5 mm² |
| Flexible, min. H05(07) V-K: | 2.5 mm² |
| Flexible, max. H05(07) V-K: | 0.5 mm² |
| Flexible with sleeve, max.: | 0.5 mm² |
| Flexible with sleeve, min.: | 2.5 mm² |
| Ferrule with plastic collar, max.: | 0.5 mm² |
| Wire cross-section, min. AWG: | AWG 14 |
| Wire cross-section, max. AWG: | AWG 26 |
| Tightening torque, min.: | 0.4 Nm |
| Tightening torque, max.: | 0.5 Nm |
| Stripping length: | 10 mm |
| ETIM 6.0: | EC002584 |
| ETIM 7.0: | EC002584 |
| eClass 9.0: | 27-33-02-92 |
| eClass 9.1: | 27-24-22-92 |
| eClass 10.0: | 27-33-02-92 |
| UNSPSC: | 30-21-18-01 |
| ROHS: | Conform |
