2456860000
ACT20P-AI-AO-DC-P
Poproś o ofertę
Prawa autorskie do obrazu: Weidmueller
Weidmueller 2456860000
ACT20P-AI-AO-DC-P
Na prośbę. Prześlij nam wiadomość e-mail z zapytaniem o cenę i dostępność.
"ucnguBrctvdgcxgt0eqo"
Opis
Parametry techniczne
| Type: | ACT20P-AI-AO-DC-P |
| Order No.: | 2456860000 |
| Version: | Signal converter/isolator, universal, Input : I/U universal, Output : I/U universal |
| GTIN (EAN): | 4050118471793 |
| Qty.: | 1 pc(s). |
| Width: | 12.5 mm |
| Width (inches): | 0.492 inch |
| Height: | 127.1 mm |
| Height (inches): | 5.004 inch |
| Depth: | 113.7 mm |
| Depth (inches): | 4.476 inch |
| Net weight: | 80 g |
| Humidity: | 10…90 %, no condensation |
| Operating temperature, max.: | 60 °C |
| Operating temperature, min.: | -20 °C |
| Storage temperature, max.: | 70 °C |
| Storage temperature, min.: | -25 °C |
| Operating temperature: | -20 °C...60 °C |
| Storage temperature: | -25 °C...70 °C |
| REACH SVHC: | Lead 7439-92-1 |
| Number of inputs: | 1 |
| Sensor supply: | 24 V DC |
| Input voltage: | configurable, 0-11 V (min. measurement range 2 V) |
| Input resistance, voltage: | ≥ 1 MΩ |
| Input current: | configurable, 0-22 mA (min. measurement range 4 mA) |
| Input resistance, current: | 100 Ω |
| Resolution: | 3.5 µA / 1.76 mV per bit |
| Number of outputs: | 1 |
| Output voltage, note: | Adjustable, 0...11 V, Output range, min, 2 V |
| Output current: | Adjustable, 0...22 mA, Output range, min, 4 mA |
| load impedance voltage: | > 600 Ω @ 10 V |
| Load impedance current: | 1 kΩ @ 20 mA |
| Offset voltage: | ≤ 20 mV |
| Configuration: | DIP switch, Keys and LED display, with reference voltage/current sources |
| Galvanic isolation: | 3-way isolator, between input ⁄ output ⁄ supply |
| Linearity: | < ± 0.1 % of signal range, Typ. ± 0.05 % of signal range |
| Long-term drift: | 0.1 % / 10.000 h |
| Power consumption, typ.: | 3 W |
| Rail: | TS 35 |
| Step response time: | 350 ms |
| Temperature coefficient: | < 0.05 % / °C |
| Voltage supply: | 12...60 V DC |
| EMC standards: | IEC 61326-1 |
| Galvanic isolation: | 3-way isolator, between input ⁄ output ⁄ supply |
| Impulse withstand voltage: | 4 kV (1.2/50 µs) |
| Insulation voltage: | 2 kV inputs / outputs |
| Pollution severity: | 2 |
| Surge voltage category: | III |
| Type of connection: | PUSH IN |
| Wire connection cross section AWG, min.: | AWG 26 |
| Wire connection cross section AWG, max.: | AWG 14 |
| Wire cross-section, solid, min.: | 0.2 mm² |
| Wire cross-section, solid, max.: | 2.5 mm² |
| Wire connection cross-section, finely stranded, min.: | 0.2 mm² |
| Wire connection cross section, finely stranded, max.: | 2.5 mm² |
| Wire connection cross-section, finely stranded with wire-end ferrules DIN 46228/4, min.: | 0.2 mm² |
| Wire connection cross-section, finely stranded with wire-end ferrules DIN 46228/4, max.: | 2.5 mm² |
| ETIM 6.0: | EC002653 |
| ETIM 7.0: | EC002653 |
| eClass 9.0: | 27-21-01-20 |
| eClass 9.1: | 27-21-01-90 |
| eClass 10.0: | 27-21-01-20 |
| ROHS: | Conform |
| Type: | ACT20P-AI-AO-DC-P |
| Order No.: | 2456860000 |
| Version: | Signal converter/isolator, universal, Input : I/U universal, Output : I/U universal |
| GTIN (EAN): | 4050118471793 |
| Qty.: | 1 pc(s). |
| Width: | 12.5 mm |
| Width (inches): | 0.492 inch |
| Height: | 127.1 mm |
| Height (inches): | 5.004 inch |
| Depth: | 113.7 mm |
| Depth (inches): | 4.476 inch |
| Net weight: | 80 g |
| Humidity: | 10…90 %, no condensation |
| Operating temperature, max.: | 60 °C |
| Operating temperature, min.: | -20 °C |
| Storage temperature, max.: | 70 °C |
| Storage temperature, min.: | -25 °C |
| Operating temperature: | -20 °C...60 °C |
| Storage temperature: | -25 °C...70 °C |
| REACH SVHC: | Lead 7439-92-1 |
| Number of inputs: | 1 |
| Sensor supply: | 24 V DC |
| Input voltage: | configurable, 0-11 V (min. measurement range 2 V) |
| Input resistance, voltage: | ≥ 1 MΩ |
| Input current: | configurable, 0-22 mA (min. measurement range 4 mA) |
| Input resistance, current: | 100 Ω |
| Resolution: | 3.5 µA / 1.76 mV per bit |
| Number of outputs: | 1 |
| Output voltage, note: | Adjustable, 0...11 V, Output range, min, 2 V |
| Output current: | Adjustable, 0...22 mA, Output range, min, 4 mA |
| load impedance voltage: | > 600 Ω @ 10 V |
| Load impedance current: | 1 kΩ @ 20 mA |
| Offset voltage: | ≤ 20 mV |
| Configuration: | DIP switch, Keys and LED display, with reference voltage/current sources |
| Galvanic isolation: | 3-way isolator, between input ⁄ output ⁄ supply |
| Linearity: | < ± 0.1 % of signal range, Typ. ± 0.05 % of signal range |
| Long-term drift: | 0.1 % / 10.000 h |
| Power consumption, typ.: | 3 W |
| Rail: | TS 35 |
| Step response time: | 350 ms |
| Temperature coefficient: | < 0.05 % / °C |
| Voltage supply: | 12...60 V DC |
| EMC standards: | IEC 61326-1 |
| Galvanic isolation: | 3-way isolator, between input ⁄ output ⁄ supply |
| Impulse withstand voltage: | 4 kV (1.2/50 µs) |
| Insulation voltage: | 2 kV inputs / outputs |
| Pollution severity: | 2 |
| Surge voltage category: | III |
| Type of connection: | PUSH IN |
| Wire connection cross section AWG, min.: | AWG 26 |
| Wire connection cross section AWG, max.: | AWG 14 |
| Wire cross-section, solid, min.: | 0.2 mm² |
| Wire cross-section, solid, max.: | 2.5 mm² |
| Wire connection cross-section, finely stranded, min.: | 0.2 mm² |
| Wire connection cross section, finely stranded, max.: | 2.5 mm² |
| Wire connection cross-section, finely stranded with wire-end ferrules DIN 46228/4, min.: | 0.2 mm² |
| Wire connection cross-section, finely stranded with wire-end ferrules DIN 46228/4, max.: | 2.5 mm² |
| ETIM 6.0: | EC002653 |
| ETIM 7.0: | EC002653 |
| eClass 9.0: | 27-21-01-20 |
| eClass 9.1: | 27-21-01-90 |
| eClass 10.0: | 27-21-01-20 |
| ROHS: | Conform |
