Produkt
Weidmueller
1194490000
CP T SNT2 360 W 24 V 15 A
Poproś o ofertę
Prawa autorskie do obrazu: Weidmueller
Weidmueller 1194490000
CP T SNT2 360 W 24 V 15 A
2467110000
Na prośbę. Prześlij nam wiadomość e-mail z zapytaniem o cenę i dostępność.
"ucnguBrctvdgcxgt0eqo"
Opis
Parametry techniczne
| Delivery status: | This article will no longer be available in the future. |
| Available until: | 2019-06-30 |
| Type: | CP T SNT2 360 W 24 V 15 A |
| Order No.: | 1194490000 |
| Version: | Power supply, switch-mode power supply unit, 24 V |
| GTIN (EAN): | 4032248977246 |
| Qty.: | 1 pc(s). |
| Width: | 80 mm |
| Width (inches): | 3.15 inch |
| Height: | 125 mm |
| Height (inches): | 4.921 inch |
| Depth: | 125 mm |
| Depth (inches): | 4.921 inch |
| Net weight: | 1,500 g |
| Humidity: | 0...95 % (no condensation) |
| Operating temperature, max.: | 70 °C |
| Operating temperature, min.: | -25 °C |
| Storage temperature, max.: | 85 °C |
| Storage temperature, min.: | -25 °C |
| Operating temperature: | -25 °C...70 °C |
| Storage temperature: | -25 °C...85 °C |
| REACH SVHC: | Lead 7439-92-1 |
| AC input voltage range: | 85…132 V AC, 187…550 V AC |
| Connection system: | Screw connection |
| Frequency range AC: | 50 / 60 Hz |
| Inrush current: | < 23 A @ 230 V AC |
| Rated input voltage: | 100…500 V AC (switchable) |
| Wire connection method: | Screw connection |
| Continous output current @ UNominal: | 15 A @ 40 °C, 6.7 A @ 60 °C, 10 A @ 60 °C |
| Nominal output current for Unom: | 15 A @ 40 °C |
| Output power: | 360 W |
| Output voltage: | 24 V |
| Output voltage: | 24...28 V (adjustable via potentiometer on front) |
| Output voltage type: | DC |
| Parallel connection option: | Yes |
| Rated output voltage: | 24 V DC ± 1 % |
| Wire connection method: | Screw connection |
| AC failure bridging time @ Inom: | min. 20 ms |
| Degree of efficiency: | Typ.: 88 % |
| Housing version: | Metal, corrosion resistant |
| Humidity: | 0...95 % (no condensation) |
| Indication: | Dual LED Operational: green LED, Error: red LED |
| MTBF: | > 0.9 mill. h |
| Mounting position, installation notice: | Horizontal on TS35 rail, with 80 mm of clearance at top and bottom for air circulation; can be aligned side-by-side with 50 mm gap in between. |
| Operating temperature: | -25 °C...70 °C |
| Protection degree: | IP20 |
| Short-circuit protection: | Yes |
| Limiting of mains voltage harmonic currents: | According to EN 61000-3-2 |
| Noise emission in accordance with EN55032: | Class B |
| Vibration resistance IEC 60068-2-6: | 3 axes, sinus, 10…55 Hz, 1 g, 1 oct/min. |
| Interference immunity test acc. to: | EN 61000-4-2 (ESD)|EN 61000-4-3 and EN 61000-4-8 (fields)|EN 61000-4-4 (burst)|EN 61000-4-5 (surge)|EN 61000-4-6 (conducted)|EN 61000-4-11 (dips) |
| Shock resistance IEC 60068-2-27: | 3 axes, half sinus, 15 g, 11 ms |
| Insulation voltage: | 4 kV (input / output) |
| Pollution severity: | 2 |
| Protection class: | I, with PE connection |
| Electrical machine equipment: | Acc. to EN60204 |
| For use with electronic equipment: | Acc. to EN50178 / VDE0160 |
| Safety extra-low voltage: | SELV according to EN 60950 |
| Safety transformers for switch-mode power supplies: | According to EN 61558-2-4 |
| Conductor cross-section, AWG/kcmil , max.: | 10 |
| Conductor cross-section, AWG/kcmil , min.: | 18 |
| Conductor cross-section, flexible , min.: | 1 mm² |
| Conductor cross-section, rigid , max.: | 4 mm² |
| Conductor cross-section, rigid , min.: | 1 mm² |
| Connection system: | Screw connection |
| Number of terminals: | 3 for L/N/PE |
| Tightening torque, max.: | 0.6 Nm |
| Tightening torque, min.: | 0.5 Nm |
| Wire connection cross section, flexible (input), max.: | 4 mm² |
| Conductor cross-section, AWG/kcmil , max.: | 10 |
| Conductor cross-section, AWG/kcmil , min.: | 12 |
| Conductor cross-section, flexible , max.: | 4 mm² |
| Conductor cross-section, flexible , min.: | 2.5 mm² |
| Conductor cross-section, rigid , max.: | 4 mm² |
| Conductor cross-section, rigid , min.: | 2.5 mm² |
| Number of terminals: | 4 (++ / --) |
| Tightening torque, max.: | 0.6 Nm |
| Tightening torque, min.: | 0.5 Nm |
| Number of terminals: | 3 |
| Wire connection method: | Pluggable screw connection |
| Wire cross-section, AWG/kcmil , max.: | 12 |
| Wire cross-section, AWG/kcmil , min.: | 32 |
| Wire cross-section, solid , max.: | 2.5 mm² |
| Wire cross-section, solid , min.: | 0.2 mm² |
| Active output signal: | 22 V DC ± 2 V DC / max. 20 mA |
| Power Good Signal: | Trigger point 18…22 V DC |
| Certificate No. (CSA): | 246286-2148800 |
| ETIM 6.0: | EC002540 |
| ETIM 7.0: | EC002540 |
| eClass 9.0: | 27-04-07-01 |
| eClass 9.1: | 27-04-07-01 |
| eClass 10.0: | 27-04-07-01 |
| ROHS: | Conform |
| Delivery status: | This article will no longer be available in the future. |
| Available until: | 2019-06-30 |
| Type: | CP T SNT2 360 W 24 V 15 A |
| Order No.: | 1194490000 |
| Version: | Power supply, switch-mode power supply unit, 24 V |
| GTIN (EAN): | 4032248977246 |
| Qty.: | 1 pc(s). |
| Width: | 80 mm |
| Width (inches): | 3.15 inch |
| Height: | 125 mm |
| Height (inches): | 4.921 inch |
| Depth: | 125 mm |
| Depth (inches): | 4.921 inch |
| Net weight: | 1,500 g |
| Humidity: | 0...95 % (no condensation) |
| Operating temperature, max.: | 70 °C |
| Operating temperature, min.: | -25 °C |
| Storage temperature, max.: | 85 °C |
| Storage temperature, min.: | -25 °C |
| Operating temperature: | -25 °C...70 °C |
| Storage temperature: | -25 °C...85 °C |
| REACH SVHC: | Lead 7439-92-1 |
| AC input voltage range: | 85…132 V AC, 187…550 V AC |
| Connection system: | Screw connection |
| Frequency range AC: | 50 / 60 Hz |
| Inrush current: | < 23 A @ 230 V AC |
| Rated input voltage: | 100…500 V AC (switchable) |
| Wire connection method: | Screw connection |
| Continous output current @ UNominal: | 15 A @ 40 °C, 6.7 A @ 60 °C, 10 A @ 60 °C |
| Nominal output current for Unom: | 15 A @ 40 °C |
| Output power: | 360 W |
| Output voltage: | 24 V |
| Output voltage: | 24...28 V (adjustable via potentiometer on front) |
| Output voltage type: | DC |
| Parallel connection option: | Yes |
| Rated output voltage: | 24 V DC ± 1 % |
| Wire connection method: | Screw connection |
| AC failure bridging time @ Inom: | min. 20 ms |
| Degree of efficiency: | Typ.: 88 % |
| Housing version: | Metal, corrosion resistant |
| Humidity: | 0...95 % (no condensation) |
| Indication: | Dual LED Operational: green LED, Error: red LED |
| MTBF: | > 0.9 mill. h |
| Mounting position, installation notice: | Horizontal on TS35 rail, with 80 mm of clearance at top and bottom for air circulation; can be aligned side-by-side with 50 mm gap in between. |
| Operating temperature: | -25 °C...70 °C |
| Protection degree: | IP20 |
| Short-circuit protection: | Yes |
| Limiting of mains voltage harmonic currents: | According to EN 61000-3-2 |
| Noise emission in accordance with EN55032: | Class B |
| Vibration resistance IEC 60068-2-6: | 3 axes, sinus, 10…55 Hz, 1 g, 1 oct/min. |
| Interference immunity test acc. to: | EN 61000-4-2 (ESD)|EN 61000-4-3 and EN 61000-4-8 (fields)|EN 61000-4-4 (burst)|EN 61000-4-5 (surge)|EN 61000-4-6 (conducted)|EN 61000-4-11 (dips) |
| Shock resistance IEC 60068-2-27: | 3 axes, half sinus, 15 g, 11 ms |
| Insulation voltage: | 4 kV (input / output) |
| Pollution severity: | 2 |
| Protection class: | I, with PE connection |
| Electrical machine equipment: | Acc. to EN60204 |
| For use with electronic equipment: | Acc. to EN50178 / VDE0160 |
| Safety extra-low voltage: | SELV according to EN 60950 |
| Safety transformers for switch-mode power supplies: | According to EN 61558-2-4 |
| Conductor cross-section, AWG/kcmil , max.: | 10 |
| Conductor cross-section, AWG/kcmil , min.: | 18 |
| Conductor cross-section, flexible , min.: | 1 mm² |
| Conductor cross-section, rigid , max.: | 4 mm² |
| Conductor cross-section, rigid , min.: | 1 mm² |
| Connection system: | Screw connection |
| Number of terminals: | 3 for L/N/PE |
| Tightening torque, max.: | 0.6 Nm |
| Tightening torque, min.: | 0.5 Nm |
| Wire connection cross section, flexible (input), max.: | 4 mm² |
| Conductor cross-section, AWG/kcmil , max.: | 10 |
| Conductor cross-section, AWG/kcmil , min.: | 12 |
| Conductor cross-section, flexible , max.: | 4 mm² |
| Conductor cross-section, flexible , min.: | 2.5 mm² |
| Conductor cross-section, rigid , max.: | 4 mm² |
| Conductor cross-section, rigid , min.: | 2.5 mm² |
| Number of terminals: | 4 (++ / --) |
| Tightening torque, max.: | 0.6 Nm |
| Tightening torque, min.: | 0.5 Nm |
| Number of terminals: | 3 |
| Wire connection method: | Pluggable screw connection |
| Wire cross-section, AWG/kcmil , max.: | 12 |
| Wire cross-section, AWG/kcmil , min.: | 32 |
| Wire cross-section, solid , max.: | 2.5 mm² |
| Wire cross-section, solid , min.: | 0.2 mm² |
| Active output signal: | 22 V DC ± 2 V DC / max. 20 mA |
| Power Good Signal: | Trigger point 18…22 V DC |
| Certificate No. (CSA): | 246286-2148800 |
| ETIM 6.0: | EC002540 |
| ETIM 7.0: | EC002540 |
| eClass 9.0: | 27-04-07-01 |
| eClass 9.1: | 27-04-07-01 |
| eClass 10.0: | 27-04-07-01 |
| ROHS: | Conform |
Parametry logistyczne
| ECCN: | |
| Kraj pochodzenia: | DE |
| EAN: | 4032248977246 |
| Waga: | 0,00 kg |
| Długość: | 0,00 m |
| Szerokość: | 0,00 m |
| Wysokość: | 0,00 m |
